Parameter Lists

5.1.13 13-** Smart Logic Controller

Parameter Parameter description
number
13-0* SLC Settings
13-00 SL Controller Mode
13-01 Start Event
13-02 Stop Event
13-03 Reset SLC
13-1* Comparators
13-10 Comparator Operand
13-11 Comparator Operator
13-12 Comparator Value
13-1* RS Flip Flops
13-15 RS-FF Operand S
13-16 RS-FF Operand R
13-2* Timers
13-20 SL Controller Timer
13-4* Logic Rules
13-40 Logic Rule Boolean 1
13-41 Logic Rule Operator 1
13-42 Logic Rule Boolean 2
13-43 Logic Rule Operator 2
13-44 Logic Rule Boolean 3
13-5* States
13-51 SL Controller Event
13-52 SL Controller Action
13-9* User Defined Alerts
13-90 Alert Trigger
13-91 Alert Action
13-92 Alert Text
13-9* User Defined Readouts
13-97 Alert Alarm Word
13-98 Alert Warning Word
13-99 Alert Status Word
M0010001
Programming Guide
Default value
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Do not reset SLC
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] False
[0] Info
ExpressionLimit
0 N/A
0 N/A
0 N/A
Danfoss A/S © 10/2019 All rights reserved.
4-set-up Change Conver-
during sion index
operation
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
All set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -3
2 set-ups TRUE -
2 set-ups TRUE -
1 set-up TRUE -3
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Int32 5 5
Uint8
Uint8
TimD
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
VisStr[2
0]
Uint32
Uint32
Uint32
301
