4-64 Semi-Auto Bypass Set-up
Option:
[0] Off
*
[1] Enabled
3 3
3.7 Parameters: 5-** Main Menu - Digital
In/Out
3.7.1 5-0* Digital I/O Mode
Parameters for configuring the input and output using
NPN and PNP.
5-00 Digital I/O Mode
Option:
[0] PNP - Active
*
at 24V
[1] NPN - Active
at 0V
5-01 Terminal 27 Mode
Option:
[0] Input
*
[1] Output
86
®
VLT HVAC Drive FC 102
Function:
No function.
Starts the semi-automatic bypass
set-up and continues with the
procedure described in
chapter 3.6.4 Semi-Automatic Bypass
Speed Set-up.
Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Digital inputs and programmed
digital outputs are pre-
programmable for operation either
in PNP or NPN systems.
Action on positive directional
pulses. PNP systems are pulled up
to +24 V.
Action on negative directional
pulses. NPN systems are pulled
down to GND, internally in the
frequency converter.
Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Defines terminal 27 as a digital
input.
Defines terminal 27 as a digital
output.
Danfoss A/S © 10/2019 All rights reserved.
5-02 Terminal 29 Mode
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
[0] Input Defines terminal 29 as a digital
*
input.
[1] Output Defines terminal 29 as a digital
output.
3.7.2 5-1* Digital Inputs
Parameters for configuring the input functions for the
input terminals.
The digital inputs are used for selecting various functions
in the frequency converter. All digital inputs can be set to
the following functions:
Digital input function Select
No operation
Reset
Coast inverse
Coast and reset inverse
DC brake inverse
Stop inverse
External interlock
Start
Latched start
Reversing [10]
Start reversing [11]
Jog [14]
Preset reference on [15]
Preset ref bit 0 [16]
Preset ref bit 1 [17]
Preset ref bit 2 [18]
Freeze reference [19]
Freeze output [20]
Speed up [21]
Speed down [22]
Set-up select bit 0 [23]
Set-up select bit 1 [24]
Pulse input [32]
Ramp bit 0 [34]
Mains failure inverse [36]
Fire mode [37]
Run permissive [52]
Hand start [53]
Auto start [54]
DigiPot increase [55]
DigiPot decrease [56]
DigiPot clear [57]
Terminal
[0] All terminal 19, 32, 33
[1] All
[2] 27
[3] All
[5] All
[6] All
[7] All
[8] All terminal 18
[9] All
All
All
All terminal 29
All
All
All
All
All
All
All
All
All
All
Terminal 29, 33
All
All
All
All
All
All
All
All
All
