Parameter Descriptions
36-11 Terminal X49/1 Low Current
Range: Function:
4 mA [ 0 - par. Enter the current that corresponds
*
36-13 mA] to the low reference value in
parameter 36-14 Term. X49/1 Low
Ref./Feedb. Value.
36-12 Terminal X49/1 High Voltage
Range: Function:
10 V [ par. 36-10 - Enter the voltage that corresponds
*
10 V] to the high reference value in
parameter 36-15 Term. X49/1 High
Ref./Feedb. Value.
36-13 Terminal X49/1 High Current
Range: Function:
20 mA [ par. 36-11 - Enter the current that corresponds
*
20 mA] to the high reference value in
parameter 36-15 Term. X49/1 High
Ref./Feedb. Value.
36-14 Term. X49/1 Low Ref./Feedb. Value
Range: Function:
0 [-999999.999 Enter the reference or feedback
*
- 999999.999 ] value that corresponds to the
voltage or current value in
parameter 36-10 Terminal X49/1 Low
Voltage or parameter 36-11 Terminal
X49/1 Low Current.
36-15 Term. X49/1 High Ref./Feedb. Value
Range: Function:
100 [-999999.999 Enter the reference or feedback
*
- 999999.999 ] value that corresponds to the
voltage or current value in
parameter 36-12 Terminal X49/1 High
Voltage or parameter 36-13 Terminal
X49/1 High Current.
36-16 Term. X49/1 Filter Time Constant
Range: Function:
0.005 s [0.005 - 10 s] Enter the filter time constant. This
*
constant is a first-order digital low-
pass filter time for suppressing
electrical noise in terminal X49/1. A
high value improves dampening
but also increases the delay
through the filter.
36-17 Term. X49/1 Live Zero
Enable live zero monitoring.
Range: Function:
[0] Disabled
[1] Enabled
*
M0010001
Programming Guide
36-20 Terminal X49/3 Low Voltage
Range:
0.07 V
*
3.29.3 36-2* Analog Input X49/3
36-21 Terminal X49/3 Low Current
Range:
4 mA
*
36-22 Terminal X49/3 High Voltage
Range:
10 V
*
36-23 Terminal X49/3 High Current
Range:
20 mA
*
36-24 Term. X49/3 Low Ref./Feedb. Value
Range:
0
*
36-25 Term. X49/3 High Ref./Feedb. Value
Range:
100
*
36-26 Term. X49/3 Filter Time Constant
Range:
0.005 s
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
[ 0 - par. Enter the voltage that corresponds
36-22 V] to the low reference value in
parameter 36-24 Term. X49/3 Low
Ref./Feedb. Value.
Function:
[ 0 - par. Enter the current that corresponds
36-23 mA] to the low reference value in
parameter 36-24 Term. X49/3 Low
Ref./Feedb. Value.
Function:
[ par. 36-20 - Enter the voltage that corresponds
10 V] to the high reference value in
parameter 36-25 Term. X49/3 High
Ref./Feedb. Value.
Function:
[ par. 36-21 - Enter the current that corresponds
20 mA] to the high reference value in
parameter 36-25 Term. X49/3 High
Ref./Feedb. Value.
Function:
[-999999.999 Enter the reference or feedback
- 999999.999 ] value that corresponds to the
voltage or current value in
parameter 36-20 Terminal X49/3 Low
Voltage or parameter 36-21 Terminal
X49/3 Low Current.
Function:
[-999999.999 Enter the reference or feedback
- 999999.999 ] value that corresponds to the
voltage or current value in
parameter 36-22 Terminal X49/3 High
Voltage or parameter 36-23 Terminal
X49/3 High Current.
Function:
[0.005 - 10 s] Enter the filter time constant. This
constant is a first-order digital low-
pass filter time for suppressing
electrical noise in terminal X49/3. A
