Parameter Descriptions
36-61 Terminal X49/11 Digital Output
Select the function of Terminal X49/11 as an analog voltage
output.
Option: Function:
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
[154] ATEX ETR freq.
warning
[160] No alarm
[161] Running
reverse
[163] Pressure
Sensor
[165] Local ref
active
[166] Remote ref
active
[167] Start
command
activ
[168] Hand / Off
[169] Auto mode
[180] Clock Fault
[181] Prev.
Maintenance
[188] AHF Capacitor
Connect
[189] External Fan
Control
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve
Control
[196] Fire Mode
[197] Fire Mode was
Act.
[198] Drive Bypass
[200] Full capacity
[201] Pump 1
running
[202] Pump 2
running
[203] Pump 3
running
[236] Ext. CL 1 on
Ref
[237] Ext. CL 2 on
Ref
[238] Ext. CL 3 on
Ref
M0010001
Programming Guide
36-61 Terminal X49/11 Digital Output
Select the function of Terminal X49/11 as an analog voltage
output.
Option:
[240]
[241]
[242]
[243]
[244]
[245]
[246]
[247]
36-62 Terminal X49/11 Min. Scale
Range:
0 %
*
36-63 Terminal X49/11 Max. Scale
Range:
100 %
*
36-64 Terminal X49/11 Bus Control
Range:
0 %
*
36-65 Terminal X49/11 Timeout Preset
Range:
0 %
*

3.30 Parameters: 40-** Special Settings

40-40 Alarm Log: Ext. Reference
Range:
0 %
*
40-41 Alarm Log: Frequency
Range:
0 Hz
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
RS Flipflop 0
RS Flipflop 1
RS Flipflop 2
RS Flipflop 3
RS Flipflop 4
RS Flipflop 5
RS Flipflop 6
RS Flipflop 7
Function:
[0 - 200 %] Match the minimum output of
terminal X49/11 with a required
value. For more information, see
parameter 36-42 Terminal X49/7 Min.
Scale.
Function:
[0 - 200 %] Scale the maximum output of
terminal X49/11. For more
information, see
parameter 36-43 Terminal X49/7 Max.
Scale.
Function:
[0 - 100 %] This parameter contains the output
level of terminal X49/11 if the
terminal is controlled by a fieldbus.
Function:
[0 - 100 %] The frequency converter sends the
value of this parameter to the
output terminal when the terminal
is controlled by a fieldbus and a
timeout is detected.
Function:
[-200 -
200 %]
Function:
[0 - 6500 Hz]
3 3
