Parameter Descriptions
5-40 Function Relay
Array [8]
(Relay 1 [0], Relay 2 [1]
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8]).
Select options to define the function of the relays.
The selection of each mechanical relay is realized in an array
parameter.
Option: Function:
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem
ctrl
[4] Standby / no
warning
[5] Running Default setting for relay 2.
[6] Running / no
warning
[8] Run on ref/no
warn
[9] Alarm Default setting for relay 1.
[10] Alarm or
warning
[11] At torque limit
[12] Out of current
range
[13] Below current,
low
[14] Above current,
high
[15] Out of speed
range
[16] Below speed,
low
[17] Above speed,
high
[18] Out of feedb.
range
[19] Below
feedback, low
[20] Above
feedback, high
[21] Thermal
warning
[25] Reverse
[26] Bus OK
[27] Torque limit &
stop
[28] Brake, no
brake war
[29] Brake ready,
no fault
[30] Brake fault
(IGBT)
[31] Relay 123
M0010001
Programming Guide
5-40 Function Relay
Array [8]
(Relay 1 [0], Relay 2 [1]
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8]).
Select options to define the function of the relays.
The selection of each mechanical relay is realized in an array
parameter.
Option:
[33]
[35]
[36]
[37]
[40]
[41]
[42]
[45]
[46]
[47]
[51]
[59]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[81]
[82]
[83]
[84]
[85]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Safe stop
active
External
Interlock
Control word
bit 11
Control word
bit 12
Out of ref
range
Below
reference, low
Above ref,
high
Bus ctrl.
Bus ctrl, 1 if
timeout
Bus ctrl, 0 if
timeout
MCO
controlled
Remote,enable
,no TW
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Comparator 4
Comparator 5
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Logic rule 4
Logic rule 5
SL digital
output A
SL digital
output B
SL digital
output C
SL digital
output D
SL digital
output E
SL digital
output F
3 3
