Danfoss VLT FC 102 Programming Manual page 35

Parameter Descriptions
0-20 Display Line 1.1 Small
Option: Function:
[1662] Analog Input Actual value at input 53 either as a
53 reference or protection value.
[1663] Terminal 54 Setting of input terminal 54.
Switch Setting Current=0; Voltage=1.
[1664] Analog Input Actual value at input 54 either as
54 reference or protection value.
[1665] Analog Output Actual value at output 42 in mA.
42 [mA] Use parameter 6-50 Terminal 42
Output to select the variable to be
represented by output 42.
[1666] Digital Output Binary value of all digital outputs.
[bin]
[1667] Pulse Input Actual value of the frequency
#29 [Hz] applied at terminal 29 as a pulse
input.
[1668] Pulse Input Actual value of the frequency
#33 [Hz] applied at terminal 33 as a pulse
input.
[1669] Pulse Output Actual value of pulses applied to
#27 [Hz] terminal 27 in digital output mode.
[1670] Pulse Output Actual value of pulses applied to
#29 [Hz] terminal 29 in digital output mode.
[1671] Relay Output View the setting of all relays.
[bin]
[1672] Counter A View the present value of counter
A.
[1673] Counter B View the present value of counter
B.
[1675] Analog In Actual value of the signal on input
X30/11 X30/11 (general purpose I/O card.
Optional).
[1676] Analog In Actual value of the signal on input
X30/12 X30/12 (general purpose I/O card.
Optional).
[1677] Analog Out Actual value at output X30/8
X30/8 [mA] (general purpose I/O card.
Optional). Use
parameter 6-60 Terminal X30/8
Output to select the variable to be
shown.
[1678] Analog Out
X45/1 [mA]
[1679] Analog Out
X45/3 [mA]
[1680] Fieldbus CTW Control word (CTW) received from
1 the bus master.
[1682] Fieldbus REF 1 Main reference value sent with
control word via the serial
communications network, for
M0010001
Programming Guide
0-20 Display Line 1.1 Small
Option:
[1684]
[1685]
[1686]
[1687]
[1690]
[1691]
[1692]
[1693]
[1694]
[1695]
[1696]
[1697]
[1698]
[1830]
[1831]
[1832]
[1833]
[1834]
Danfoss A/S © 10/2019 All rights reserved.
Function:
example from the BMS, PLC, or
other master controller.
Comm. Option Extended fieldbus communication
STW option status word.
FC Port CTW 1 Control word (CTW) received from
the bus master.
FC Port REF 1 Status word (STW) sent to the bus
master.
Bus Readout
Alarm/Warning
Alarm Word 1 or more alarms in a hex code
(used for serial communications).
Alarm Word 2 1 or more alarms in a hex code
(used for serial communications).
Warning Word 1 or more warnings in a hex code
(used for serial communications).
Warning Word 1 or more warnings in a hex code
2 (used for serial communications).
Ext. Status 1 or more status conditions in a
Word hex code (used for serial communi-
cations).
Ext. Status 1 or more status conditions in a
Word 2 hex code (used for serial communi-
cations).
Maintenance The bits reflect the status for the
Word programmed preventive
maintenance events in parameter
group 23-1* Maintenance.
Alarm Word 3
Warning Word
3
Analog Input Shows the value of the signal
X42/1 applied to terminal X42/1 on the
analog I/O card.
Analog Input Shows the value of the signal
X42/3 applied to terminal X42/3 on the
analog I/O card.
Analog Input Shows the value of the signal
X42/5 applied to terminal X42/5 on the
analog I/O card.
Analog Out Shows the value of the signal
X42/7 [V] applied to terminal X42/7 on the
analog I/O card.
Analog Out Shows the value of the signal
X42/9 [V] applied to terminal X42/9 on the
analog I/O card.
