Parameter Descriptions
26-02 Terminal X42/5 Mode
Option: Function:
Terminal X42/5 can be programmed
as an analog input accepting a
voltage or input from either Pt
1000 (1000 Ω at 0 °C) or Ni 1000
(1000 Ω at 0 °C) temperature
sensors. Select the mode.
[2] Pt 1000 [
if operating in Celsius, or [3] Pt 1000
° F] and [5] Ni 1000 [ ° F] if operating
[
in Fahrenheit.
NOTICE
If the input is not in use, set it
for voltage.
If set for temperature and used as
feedback, set the unit for either
Celsius or Fahrenheit:
[1] Voltage
*
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
3.24.2 26-1* Analog Input X42/1
Parameters for configuring the scaling and limits for analog
input, terminal X42/1.
26-10 Terminal X42/1 Low Voltage
Range: Function:
0.07 V [ 0 - par. 6-31 Enter the low voltage value. This
*
V] analog input scaling value should
correspond to the low reference/
feedback value set in
parameter 26-14 Term. X42/1 Low
Ref./Feedb. Value.
26-11 Terminal X42/1 High Voltage
Range: Function:
10 V [ par. 6-30 - Enter the high-voltage value. This
*
10 V] analog input scaling value should
correspond to the high reference/
feedback value set in
M0010001
Programming Guide
° C] and [4] Ni 1000 [ ° C]
•
Parameter 20-12 Reference/
Feedback Unit.
•
Parameter 21-10 Ext. 1 Ref./
Feedback Unit.
•
Parameter 21-30 Ext. 2 Ref./
Feedback Unit.
•
Parameter 21-50 Ext. 3 Ref./
Feedback Unit.
Danfoss A/S © 10/2019 All rights reserved.
26-11 Terminal X42/1 High Voltage
Range: Function:
parameter 26-15 Term. X42/1 High
Ref./Feedb. Value.
26-14 Term. X42/1 Low Ref./Feedb. Value
Range: Function:
0 [-999999.999 Enter the analog input scaling value
*
- 999999.999 ] that corresponds to the low-voltage
value set in
parameter 26-10 Terminal X42/1 Low
Voltage.
26-15 Term. X42/1 High Ref./Feedb. Value
Range: Function:
100 [-999999.999 Enter the analog input scaling value
*
- 999999.999 ] that corresponds to the high-
voltage value set in
parameter 26-11 Terminal X42/1 High
Voltage.
26-16 Term. X42/1 Filter Time Constant
Range: Function:
NOTICE
0.005 s [0.005 - 10 s]
*
This parameter cannot be
adjusted while the motor is
running.
This is a first-order digital low-pass
filter time constant for suppressing
noise in terminal X42/1. A high
time constant value improves
dampening, but also increases the
time delay through the filter.
26-17 Term. X42/1 Live Zero
Option: Function:
This parameter makes it possible to
enable the live zero monitoring, for
example, where the analog input is
the frequency converter control,
rather than being used as a
decentral I/O system, such as a
building management system.
[0] Disabled
[1] Enabled
*
