Parameter Descriptions
5-90 Digital & Relay Bus Control
Range: Function:
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9–
15
Bit 16 Option C relay 1 output
Bit 17 Option C relay 2 output
Bit 18 Option C relay 3 output
Bit 19 Option C relay 4 output
Bit 20 Option C relay 5 output
Bit 21 Option C relay 6 output
Bit 22 Option C relay 7 output
Bit 23 Option C relay 8 output
Bit
24–31
Table 3.16 Digital Output Bits
5-93 Pulse Out #27 Bus Control
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to
*
the digital output terminal 27 when
it is configured as bus-controlled.
5-94 Pulse Out #27 Timeout Preset
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to
*
the digital output terminal 27 when
it is configured as bus-controlled
timeout, and timeout is detected.
M0010001
Programming Guide
CC digital output, terminal
27
CC digital output, terminal
29
GPIO digital output,
terminal X 30/6
GPIO digital output,
terminal X 30/7
CC relay 1 output terminal
CC relay 2 output terminal
Option B relay 1 output
terminal
Option B relay 2 output
terminal
Option B relay 3 output
terminal
Reserved for future
terminals
terminal
terminal
terminal
terminal
terminal
terminal
terminal
terminal
Reserved for future
terminals
Danfoss A/S © 10/2019 All rights reserved.
5-95 Pulse Out #29 Bus Control
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to
*
the digital output terminal 29 when
it is configured as bus-controlled.
5-96 Pulse Out #29 Timeout Preset
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to
*
the digital output terminal 29 when
it is configured as bus-controlled
timeout, and timeout is detected.
5-97 Pulse Out #X30/6 Bus Control
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to
*
the digital output terminal 6 when
it is configured as bus-controlled.
5-98 Pulse Out #X30/6 Timeout Preset
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to
*
the digital output terminal 6 when
it is configured as bus-controlled
timeout, and timeout is detected.
3 3
