Parameter Descriptions
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for readout on terminal X30/6.
This parameter is active when VLT
is installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
3 3
Outputs.
Option:
[93] Pressure
Sensor 3
[100] Output freq.
0-100
[101] Reference
Min-Max
[102] Feedback
+-200%
[103] Motor cur. 0-
Imax
[104] Torque 0-Tlim
[105] Torque 0-
Tnom
[106] Power 0-Pnom
[107] Speed 0-
HighLim
[113] Ext. Closed
Loop 1
[114] Ext. Closed
Loop 2
[115] Ext. Closed
Loop 3
[186] Pressure
Sensor 4
5-68 Pulse Output Max Freq #X30/6
Range:
5000 Hz
*
Hz]
104
®
General Purpose I/O MCB 101
Function:
Function:
NOTICE
[0 - 32000
This parameter cannot be
adjusted while the motor is
running.
Select the maximum frequency on
terminal X30/6 referring to the
output variable in
parameter 5-66 Terminal X30/6 Pulse
Output Variable.
This parameter is active when VLT
General Purpose I/O MCB 101 is
installed in the frequency converter.
Danfoss A/S © 10/2019 All rights reserved.
®
VLT HVAC Drive FC 102
3.7.14 5-8* I/O Options
Range:
25 s
*
3.7.15 5-9* Bus-controlled
This parameter group selects digital and relay outputs via a
fieldbus setting.
5-90 Digital & Relay Bus Control
Range:
0
*
®
Function:
[1 - 120 s] Guarantees a minimum off-time for
the capacitors. The timer starts
once the AHF capacitor disconnects
and has to expire before the output
is allowed to be on again. It only
turns on again if the frequency
converter power is 20–30%.
Function:
[0 - This parameter holds the state of
2147483647 ] the digital outputs and relays that
are controlled by bus.
A logical 1 indicates that the
output is high or active.
A logical 0 indicates that the
output is low or inactive.
M0010001
