Parameter Descriptions
23-03 OFF Action
Array [10]
Option: Function:
[26] DC Brake
[27] Coast
[32] Set digital out
A low
[33] Set digital out
B low
[34] Set digital out
C low
[35] Set digital out
D low
[36] Set digital out
E low
[37] Set digital out
F low
[38] Set digital out
A high
[39] Set digital out
B high
[40] Set digital out
C high
[41] Set digital out
D high
[42] Set digital out
E high
[43] Set digital out
F high
[60] Reset Counter
A
[61] Reset Counter
B
[62] Counter A (up)
[63] Counter A
(down)
[64] Counter B (up)
[65] Counter B
(down)
[80] Sleep Mode
[90] Set ECB
Bypass Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
23-04 Occurrence
Array [10]
Option: Function:
Select which days the timed action
applies to. Specify working/non-
working days in:
M0010001
Programming Guide
23-04 Occurrence
Array [10]
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
Danfoss A/S © 10/2019 All rights reserved.
Function:
•
Parameter 0-81 Working
Days.
•
Parameter 0-82 Additional
Working Days.
•
Parameter 0-83 Additional
Non-Working Days.
All days
Working days
Non-working
days
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Day 1 of
month
Day 2 of
month
Day 3 of
month
Day 4 of
month
Day 5 of
month
Day 6 of
month
Day 7 of
month
Day 8 of
month
Day 9 of
month
Day 10 of
month
Day 11 of
month
Day 12 of
month
Day 13 of
month
Day 14 of
month
Day 15 of
month
Day 16 of
month
Day 17 of
month
