Danfoss VLT FC 102 Programming Manual page 145

Parameter Descriptions
13-51 SL Controller Event
Array [20]
Option: Function:
[95] RS Flipflop 1 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[96] RS Flipflop 2 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[97] RS Flipflop 3 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[98] RS Flipflop 4 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[99] RS Flipflop 5 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[100] Fire Mode See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[101] RS Flipflop 7 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[103] Relay 1
[104] Relay 2
[109] Relay 7
[110] Relay 8
[111] Relay 9
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur.
alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq.
alarm
[144] Pressure 1
Low
[145] Pressure 2
Low
[146] Pressure 3
Low
[147] Pressure 4
Low
[148] Pressure 1
High
[149] Pressure 2
High
[150] Pressure 3
High
[151] Pressure 4
High
M0010001
Programming Guide
13-52 SL Controller Action
Array [20]
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[22]
[23]
[24]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Select the action corresponding to
the SLC event. Actions are executed
when the corresponding event
(defined in parameter 13-51 SL
Controller Event) is evaluated as
true. The following actions are
available for selection:
Disabled
No action
Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to 1.
Select set-up 2 Changes the active set-up
(parameter 0-10 Active Set-up) to 2.
Select set-up 3 Changes the active set-up
(parameter 0-10 Active Set-up) to 3.
Select set-up 4 Changes the active set-up
(parameter 0-10 Active Set-up) to 4.
If the set-up is changed, it merges
with other set-up commands
coming from either the digital
inputs or via a fieldbus.
Select preset Selects preset reference 0.
ref 0
Select preset Selects preset reference 1.
ref 1
Select preset Selects preset reference 2.
ref 2
Select preset Selects preset reference 3.
ref 3
Select preset Selects preset reference 4.
ref 4
Select preset Selects preset reference 5.
ref 5
Select preset Selects preset reference 6.
ref 6
Select preset Selects preset reference 7. If the
ref 7 active preset reference is changed,
it merges with other preset
reference commands coming from
either the digital inputs or via a
fieldbus.
Select ramp 1 Selects ramp 1.
Select ramp 2 Selects ramp 2.
Run Issues a start command to the
frequency converter.
Run reverse Issues a start reverse command to
the frequency converter.
Stop Issues a stop command to the
frequency converter.
3 3
