Parameter Descriptions
1-16 High Speed Filter Time Const.
Range: Function:
unstable. This time constant is used
above 10% rated speed.
1-17 Voltage filter time const.
Range: Function:
Size [0.001 - 2 s] Supply voltage filter time constant
related is used for reducing the influence
*
of high frequency ripples and
system resonances in the
calculation of machine supply
voltage. Without this filter, the
ripples in the currents can distort
the calculated voltage and affect
the stability of the system.
3.3.5 1-2* Motor Data
This parameter group contains input data from the
nameplate on the connected motor.
NOTICE
Changing the value of these parameters affects the
setting of other parameters.
NOTICE
The following parameters have no effect when
parameter 1-10 Motor Construction is set to [1] PM, non-
salient SPM, [2] PM, salient IPM, [5] Sync. Reluctance:
•
Parameter 1-20 Motor Power [kW].
•
Parameter 1-21 Motor Power [HP].
•
Parameter 1-22 Motor Voltage.
•
Parameter 1-23 Motor Frequency.
1-20 Motor Power [kW]
Range: Function:
Size [ 0.09 - Enter the nominal motor power in
related 3000.00 kW] kW according to the motor
*
nameplate data. The default value
corresponds to the nominal rated
output of the unit.
Depending on the selections made
in parameter 0-03 Regional Settings,
either parameter 1-20 Motor Power
[kW] or parameter 1-21 Motor Power
[HP] is made invisible.
M0010001
Programming Guide
1-21 Motor Power [HP]
Range:
Size
related
*
1-22 Motor Voltage
Range:
Size
related
*
1-23 Motor Frequency
Range:
Size
related
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
NOTICE
[ 0.09 -
3000.00 hp]
This parameter cannot be
adjusted while the motor is
running.
Enter the nominal motor power in
hp according to the motor
nameplate data. The default value
corresponds to the nominal rated
output of the unit.
Depending on the selections made
in parameter 0-03 Regional Settings,
either parameter 1-20 Motor Power
[kW] or parameter 1-21 Motor Power
[HP] is made invisible.
Function:
[ 10 - 1000 Enter the nominal motor voltage
V] according to the motor nameplate
data. The default value corresponds
to the nominal rated output of the
frequency converter.
Function:
NOTICE
[20 - 1000
Hz]
This parameter cannot be
adjusted while the motor is
running.
Select the motor frequency value
from the motor nameplate data. For
87 Hz operation with 230/400 V
motors, set the nameplate data for
230 V/50 Hz. Adapt
parameter 4-13 Motor Speed High
Limit [RPM] and
parameter 3-03 Maximum Reference
to the 87 Hz application.
