Parameter Descriptions
3-15 Reference 1 Source
Option: Function:
[2] Analog Input
54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital
pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed
Loop 1
[31] Ext. Closed
Loop 2
[32] Ext. Closed
Loop 3
[37] Analog Input
X49/1
[38] Analog Input
X49/3
[39] Analog Input
X49/5
[133] Fieldbus REF 1
3-16 Reference 2 Source
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Select the reference input to be
used for the 2
Define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
[0] No function
M0010001
Programming Guide
nd
reference signal:
•
Parameter 3-15 Reference 1
Source.
•
Parameter 3-16 Reference 2
Source.
•
Parameter 3-17 Reference 3
Source.
Danfoss A/S © 10/2019 All rights reserved.
3-16 Reference 2 Source
Option: Function:
[1] Analog Input
53
[2] Analog Input
54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital
*
pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed
Loop 1
[31] Ext. Closed
Loop 2
[32] Ext. Closed
Loop 3
[37] Analog Input
X49/1
[38] Analog Input
X49/3
[39] Analog Input
X49/5
[133] Fieldbus REF 1
3-17 Reference 3 Source
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Select the reference input to be
used for the 3
Define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
rd
reference signal:
•
Parameter 3-15 Reference 1
Source.
•
Parameter 3-16 Reference 2
Source.
•
Parameter 3-17 Reference 3
Source.
