Troubleshooting
4 Troubleshooting
4.1 Troubleshooting
4.1.1 Alarms and Warnings
A warning or an alarm is signalled by the relevant LED on
the front of the frequency converter and indicated by a
code on the display.
A warning remains active until its cause is no longer
present. Under certain circumstances, operation of the
motor may still be continued.
In the event of an alarm, the frequency converter trips. To
restart operation, reset the alarms once their causes have
been rectified.
This may be done in 4 ways:
•
By resetting the [RESET] on the LCP.
•
Via a digital input with the Reset function.
•
Via serial communication/optional fieldbus.
•
By resetting automatically using the auto reset-
function, which is a default setting, see
parameter 14-20 Reset Mode.
NOTICE
After a manual reset pressing [RESET] on the LCP, press
[Auto On] or [Hand On] to restart the motor.
If an alarm cannot be reset, the reason may be that its
cause has not been rectified, or the alarm is trip-locked.
No.
Description
Warning
1
10 V low
X
2
Live zero error
(X)
3
No motor
(X)
4
Mains phase loss
(X)
M0010001
Programming Guide
Alarms that are trip-locked offer additional protection, as
the mains supply must be switched off before the alarm
can be reset. After being switched back on, the
frequency converter is no longer blocked and may be
reset as described above once the alarm cause has been
rectified.
Alarms that are not trip-locked can also be reset using
the automatic reset function in parameter 14-20 Reset
Mode (Warning: Automatic wake-up is possible!)
If a warning and alarm is marked against a code in the
Alarm/warning list table, this means that either a
warning occurs before an alarm, or it can be specified
whether it is a warning or an alarm that is to be shown
for a given fault.
This is possible, for instance, in parameter 1-90 Motor
Thermal Protection. After an alarm or trip, the motor
carries on coasting, and the alarm and warning flash on
the frequency converter. Once the problem has been
rectified, only the alarm continues flashing.
NOTICE
No missing motor phase detection (numbers 30-32) and
no stall detection are active when parameter 1-10 Motor
Construction is set to [1] PM non-salient SPM.
Alarm/
Alarm/
Parameter
trip
trip lock
reference
–
–
Parameter 6-01
Live Zero Timeout
Function, Parameter
(X)
–
6-02
Fire Mode Live Zero
Timeout Function
Parameter 1-80
(X)
–
Function at Stop
Parameter 14-12
(X)
(X)
Response to Mains
Imbalance
Danfoss A/S © 10/2019 All rights reserved.
CAUTION
Fire mode alarm handling selected
in parameter 24-09 Fire Mode Alarm
Handling
Critical alarms cause a trip.
[0] Trip +
[1] Trip
Reset
–
Ignored
Ignored
Ignored
Ignored
Ignored
Ignored
Ignored
Ignored
4
Warranty-
affecting
alarms
in fire
mode
[2] Test
–
Warning
–
(Warning /
–
Trip)
(Warning /
–
Trip)
(Warning /
X
Trip)
273
4
