5. Nios II Core Implementation Details
NII-PRG | 2018.04.18
Up to one instruction is dispatched and/or retired per cycle. Instructions are
dispatched and retired in-order. Static branch prediction is implemented using the
branch offset direction; a negative offset (backward branch) is predicted as taken, and
a positive offset (forward branch) is predicted as not taken. The pipeline stalls for the
following conditions:
•
Multicycle instructions (e.g., shift/rotate without hardware multiply)
•
Avalon-MM instruction master port read accesses
•
Avalon-MM data master port read/write accesses
•
Data dependencies on long latency instructions (e.g., load, multiply, shift
operations)
5.3.5.1. Pipeline Stalls
The pipeline is set up so that if a stage stalls, no new values enter that stage or any
earlier stages. No "catching up" of pipeline stages is allowed, even if a pipeline stage
is empty.
Only the M-stage is allowed to create stalls.
The M-stage stall occurs if any of the following conditions occurs:
•
An M-stage load/store instruction is waiting for Avalon-MM data master transfer to
complete.
•
An M-stage shift/rotate instruction is still performing its operation when using the
multicycle shift circuitry (i.e., when the hardware multiplier is not available).
•
An M-stage shift/rotate/multiply instruction is still performing its operation when
using the hardware multiplier (which takes three cycles).
•
An M-stage multicycle custom instruction is asserting its stall signal. This only
occurs if the design includes multicycle custom instructions.
5.3.5.2. Branch Prediction
The Nios II/s core performs static branch prediction to minimize the cycle penalty
associated with taken branches.
5.3.6. Instruction Performance
All instructions take one or more cycles to execute. Some instructions have other
penalties associated with their execution. Instructions that flush the pipeline cause up
to three instructions after them to be cancelled. This creates a three-cycle penalty and
an execution time of four cycles. Instructions that require an Avalon-MM transfer are
stalled until the transfer completes.
Table 74.
Instruction Execution Performance for Nios II/s Core
Instruction
Normal ALU instructions (e.g.,
)
cmplt
Combinatorial custom instructions
Multicycle custom instructions
Cycles
,
add
> 1
1
1
Penalties
continued...
Nios II Processor Reference Guide
139
