Disassembly/Assembly > External Cover/Interior System > Layout Drawing > Reader Unit

External Cover/Interior System

Layout Drawing

■ ADF UNIT
[5]
[4]
[3]
No. Parts Name
[1] Original Tray
[2] ADF Base
[3] Feeder Cover
[4] ADF Rear Cover
[5] ADF Side Guide Plate
4 Disassembly/Assembly > External Cover/Interior System > Layout Drawing > Reader Unit
[1]
[2]
F-4-39
Reference
T-4-38
■ Reader Unit
[3]
[4]
No. Parts Name
[1] Copyboard Glass Unit
[2] Reader Rear Cover 1
[3] Reader Rear Cover 2
[4] Reader Motor Cover
4-30
[2]
[1]
F-4-40
Reference
(Refer to page 4-69)
T-4-39
