Adjustment > Document Exposure System > When clearing the Reader-related RAM data of the Main Controller PCB.
When clearing the Reader-related RAM data of the
Main Controller PCB.
Points to note before replacing the Reader Controller PCB:
• Back up the service mode setting values related to Main Controller PCB. (Excluding
the case where service mode cannot be executed due to the Main Controller PCB
not operating normally)
Use a USB memory
COPIER > FUNCTION > SYSTEM > EXPORT
1) Perform RAM clear.
COPIER > FUNCTION > CLEAR >
2) Turn OFF/ON the main power switch.
When backup is performed normally
4) Import the service mode data backed up before replacement from the USB memory.
COPIER > FUNCTION > SYSTEM
NOTE:
Work is completed when backup was normally performed.
5 Adjustment > Document Exposure System > When clearing the Reader-related RAM data of the Main Controller PCB.
R-CON
T-5-3
IMPORT
T-5-4
When backup is not performed normally
5) Enter the values written on the service label (on the back of the Front Cover).
COPIER > ADJUST > ADJ-XY >
ADJ-X ADJ-Y
COPIER > ADJUST > CCD >
W-PLT-X W-PLT-Y
50-RG 50-GB
50DF-RG 50DF-GB
MTF2-M1 MTF2-M6
MTF2-M2 MTF2-M7
MTF2-M3 MTF2-M8
MTF2-M4 MTF2-M9
MTF2-M5 -
MTF-M1 MTF-M6
MTF-M2 MTF-M7
MTF-M3 MTF-M8
MTF-M4 MTF-M9
MTF-M5 -
COPIER > ADJUST > PASCAL >
OFST-P-Y OFST-P-M
FEEDER > ADJUST >
DOCST LA-SPEED
ADJ-X-MG ADJ-Y-DF
T-5-5
W-PLT-Z -
100-RG 100-GB
100DF-RG 100DF-GB
MTF2-S1 MTF2-S6
MTF2-S2 MTF2-S7
MTF2-S3 MTF2-S8
MTF2-S4 MTF2-S9
MTF2-S5 -
MTF-S1 MTF-S6
MTF-S2 MTF-S7
MTF-S3 MTF-S8
MTF-S4 MTF-S9
MTF-S5 -
T-5-6
OFST-P-C OFST-P-K
T-5-7
DOCST2 LASPD2 DOCSTDUP
T-5-8
