Technical Explanation > Embedded RDS > Troubleshooting
(c) Select [IPv4 Settings] > [PING Command], enter the primary DNS server noted down
in step a) as the IP address, and touch the [Apply] button.
Does the screen display "Response from the host."?
YES: Proceed to Remedy 2.
NO: Enter the secondary DNS server noted down in step a) as the IP address, and
then touch the [Apply] button.
Does the screen display "Response from the host."?
YES: Proceed to Remedy 2.
NO: There is a possibility that the DNS server address is wrong. Reconfirm the
address with the user's system administrator.
Remedy 2: Troubleshooting using communication error log (COM-LOG)
1) Start [Service Mode].
2) Select [COPIER] > [FUNCTION] > [INSTALL] > [COM-LOG].
The communication error log list screen is displayed.
3) When a code is displayed, take an appropriate action referring to "Error code and strings".
No.2
Symptom: A communication test results NG! even if network setting is set properly.
Cause: The network environment is inappropriate, or RGW-PORT settings for E-RDS have
been changed.
Remedy: The following points should be checked.
1) Check network conditions such as proxy server settings and so on.
2) Check the E-RDS setting values.
• Check the communication error log from COM-LOG.
• Check RGW-PORT settings has changed. If RGW-PORT settings has changed, restore
initial values. For initial values, see "Service cautions".
2 Technical Explanation > Embedded RDS > Troubleshooting
No.3
Symptom: Registration information of the E-RDS machine was deleted from the device
information on Web Portal, and then registered again. After that, if a communication test is
left unperformed, the device setting in the UGW becomes invalid.
Cause: When the registration information of the E-RDS machine is deleted, information
related to E-RDS is also deleted.
Therefore, when 7 days have passed without performing a communication test after
registering the E-RDS machine again, the device setting becomes invalid.
Remedy: Perform a communication test before the device setting becomes invalid.
No.4
Symptom: There was a log, indicating "Network is not ready, try later" in error details of COM-
LOG list.
Cause: A certain problem occurred in networking.
Remedy: Check and take actions mentioned below.
1) Check networking conditions and connections.
2) Turn on the power supply of this machine and perform a communication test about 60
seconds later.
No.5
Symptom: "Unknown error" is displayed though a communication test (COM-TEST) has done
successfully.
Cause: It could be a problem at the UGW side or the network load is temporarily faulty.
Remedy: Try again after a period of time. If the same error persists, check the UGW status
with a network and UGW administrator.
No.6
Symptom: When a communication test (COM-TEST) is repeatedly executed, an error occurs.
Cause: During communication conducted after execution of a COM-TEST, another COM-
TEST was executed again.
Remedy: When repeatedly executing COM-TEST, execute COM-TEST at intervals of 5
minutes or more.
