Technical Explanation > Fixing System > Controls > Protection function
Code
E009 Film unit engagement / disengagement error
0001 Signal of the Fixing Pressure Release Sensor could not be detected
at pressure application operation of the Fixing Pressure Release Cam,
and the operation was not completed within 4 sec from the start of
counterclockwise rotation of the Fixing Motor.
0002 Signal of the Fixing Pressure Release Sensor could not be detected
at pressure release operation of the Fixing Pressure Release Cam,
and the operation was not completed within 4 sec from the start of
counterclockwise rotation of the Fixing Motor.
0003 Signal of the Fixing Pressure Release Sensor could not be detected
at pressure application operation of the Fixing Pressure Release Cam,
and the operation was not completed within 3 times from the start of
counterclockwise rotation of the Fixing Motor.
0004 Signal of the Fixing Pressure Release Sensor could not be detected
at pressure release operation of the Fixing Pressure Release Cam,
and the operation was not completed within 3 times from the start of
counterclockwise rotation of the Fixing Motor.
E808 Error in zero cross signal
0001 An electrical trouble caused by zero cross signal error.
0002 An electrical trouble caused by zero cross signal error.
● Remedy at occurrence of the Fixing Assembly error (E001/E002/
E003)
Previously, if the error (E001/E002/E003) relating to the Fixing Assembly occurred, a service
visit was necessary to clear the error in service mode (COPIER > FUNCTION > CLEAR >
ERR). (This included an incidental error occurrence.)
This machine treats E001/E002/E003 errors as follows to avoid a service visit just for clearing
these errors.
• 1st error detection: The error avoidance jam (00-0CF1) is displayed.
• 2nd and later error detection: An error code (E001/E002/E003) is displayed. (Detail Code:
Axxx*)
• If the issue occurred incidentally: The error can be recovered by turning OFF and then
ON the main power switch.
• If there is an issue with the Fixing Assembly: The same error is displayed after turning
OFF and then ON the main power switch.
* 1st digit of detail code is "A": This indicates that "clearing the error in service mode
(COPIER > FUNCTION > CLEAR > ERR) is unnecessary".
2 Technical Explanation > Fixing System > Controls > Protection function
Clearing
Description
of error
Not
required
Not
required
Not
required
Not
required
Not
required
Not
required
T-2-42
