COPIER> DISPLAY> HV-STS
1ATVC-C Dspl of primary transfer current (C)
Details To display the decuple value of the current flown to the Primary Transfer
Roller (C) by the primary transfer ATVC control.
When the two values are out of the target value range (50 to 700), clear
the log information for the appropriate control (COPIER> FUNCTION>
CLEAR> 1TR-CLR).
If the two values are both small, the Primary Transfer Roller may have
reached the end of life.
Use case When estimating the life of Primary Transfer Roller based on the
displayed value
Adj/set/operate method N/A (Display only)
Display/adj/set range 0 to 900
Unit 1 uA
Appropriate target value 50 - 700
Related service mode COPIER> FUNCTION> CLEAR> 1TR-CLR
1ATVC-C2 Dspl of primary transfer current (C)
Details To display the decuple value of the current flown to the Primary Transfer
Roller (C) by the primary transfer ATVC control.
When the two values are out of the target value range (50 to 700), clear
the log information for the appropriate control (COPIER> FUNCTION>
CLEAR> 1TR-CLR).
If the two values are both small, the Primary Transfer Roller may have
reached the end of life.
Use case When estimating the life of Primary Transfer Roller based on the
displayed value
Adj/set/operate method N/A (Display only)
Display/adj/set range 0 to 900
Unit 1 uA
Appropriate target value 50 - 700
Related service mode COPIER> FUNCTION> CLEAR> 1TR-CLR
1ATVC-C3 Dspl of primary transfer current (C)
Details To display the decuple value of the current flown to the Primary Transfer
Roller (C) by the primary transfer ATVC control.
When the two values are out of the target value range (50 to 700), clear
the log information for the appropriate control (COPIER> FUNCTION>
CLEAR> 1TR-CLR).
If the two values are both small, the Primary Transfer Roller may have
reached the end of life.
Use case When estimating the life of Primary Transfer Roller based on the
displayed value
Adj/set/operate method N/A (Display only)
Display/adj/set range 0 to 900
Unit 1 uA
Appropriate target value 50 - 700
Related service mode COPIER> FUNCTION> CLEAR> 1TR-CLR
8
Service Mode > COPIER > DISPLAY > HV-STS
8 Service Mode > COPIER > DISPLAY > HV-STS
COPIER> DISPLAY> HV-STS
1ATVC-K4 Dspl prmry trns current(Bk):full clr mod
Details To display the decuple value of the current flown to the Primary Transfer
Roller (Bk) by the primary transfer ATVC control in full color mode.
When the two values are out of the target value range (50 to 700), clear
the log information for the appropriate control (COPIER> FUNCTION>
CLEAR> 1TR-CLR).
If the two values are both small, the Primary Transfer Roller may have
reached the end of life.
Use case When estimating the life of Primary Transfer Roller based on the
displayed value
Adj/set/operate method N/A (Display only)
Display/adj/set range 0 to 900
Unit 1 uA
Appropriate target value 50 - 700
Related service mode COPIER> FUNCTION> CLEAR> 1TR-CLR
1ATVC-K42 Dspl prmry trns current(Bk):full clr mod
Details To display the decuple value of the current flown to the Primary Transfer
Roller (Bk) by the primary transfer ATVC control in full color mode.
When the two values are out of the target value range (50 to 700), clear
the log information for the appropriate control (COPIER> FUNCTION>
CLEAR> 1TR-CLR).
If the two values are both small, the Primary Transfer Roller may have
reached the end of life.
Use case When estimating the life of Primary Transfer Roller based on the
displayed value
Adj/set/operate method N/A (Display only)
Display/adj/set range 0 to 900
Unit 1 uA
Appropriate target value 50 - 700
Related service mode COPIER> FUNCTION> CLEAR> 1TR-CLR
1ATVC-K43 Dspl prmry trns current(Bk):full clr mod
Details To display the decuple value of the current flown to the Primary Transfer
Roller (Bk) by the primary transfer ATVC control in full color mode.
When the two values are out of the target value range (50 to 700), clear
the log information for the appropriate control (COPIER> FUNCTION>
CLEAR> 1TR-CLR).
If the two values are both small, the Primary Transfer Roller may have
reached the end of life.
Use case When estimating the life of Primary Transfer Roller based on the
displayed value
Adj/set/operate method N/A (Display only)
Display/adj/set range 0 to 900
Unit 1 uA
Appropriate target value 50 - 700
Related service mode COPIER> FUNCTION> CLEAR> 1TR-CLR
