COPIER> FUNCTION> SPLMAN
SPL80100
Mask setting at copyboard scanning
Display/adj/set range
0 to 1
0: Mask value according to the specifications of each job
1: No mask (0 mm)
Default value
0
SPL27354
For R&D use
Details
For R&D use
Default value
Default value is not changed.
SPL84194
ON/OFF of Embedded-RDS
Details
To set ON/OFF of Embedded-RDS function.
Use case
When using Embedded-RDS
Adj/set/operate method 1) Enter the value, and then press OK key.
2) Turn OFF/ON the main power switch.
Caution
Be sure to use ERDS, RGW-PORT, COM-TEST, COM-RSLT, and
COM-LOG as a set.
Display/adj/set range
0 to 1
0: OFF, 1: ON
Default value
0
Related service mode
COPIER> FUNCTION> INSTALL> RGW-PORT, COM-TEST, COM-
RSLT, COM-LOG
Supplement/memo
"Embedded-RDS: Function to send device information such as the
device counter, failure, and consumables to UGW via SOAP protocol
UGW (Universal Gate Way): Remote monitoring service system"
SPL32620
Switching to enable/disable PC-less update
Display/adj/set range
0 to 1
0: Disabled , 1: Enabled
Default value
1
SPL90001
Setting of toner deposit amount
Display/adj/set range
0 to 5
Default value
0
SPL90002
Setting of low screen ruling dither
Display/adj/set range
0 to 1
Default value
0
8
Service Mode > COPIER > FUNCTION > INSTALL
T-8-34
8
Service Mode > COPIER > FUNCTION > INSTALL
■ INSTALL
COPIER> FUNCTION> INSTALL
STRD-POS
Adj reading position:DADF stream reading
Details
To adjust the reading position at DADF stream reading.
After the adjustment, write the value displayed by COPIER> ADJUST>
ADJ-XY> STRD-POS in the service label.
Use case
At DADF installation/uninstallation
Adj/set/operate method 1) Close the DADF.
2) Select the item, and then press Start key.
It stops automatically.
Caution
Write the adjusted value in the service label.
Display/adj/set range
At normal termination: OK, At abnormal termination: NG
Related service mode
COPIER> ADJUST> ADJ-XY> STRD-POS
RDSHDPOS
Auto adj of Reader shading position
Details
To adjust the shading position automatically based on the result of
reading of the Standard White Plate.
Use case
• When replacing the Reading Sensor Unit
• When replacing the Copyboard Glass
• When clearing the Reader-related RAM data
Adj/set/operate method Select the item, and then press Start key.
Caution
When this item is executed, the value set by COPIER> ADJUST> ADJ-
XY> ADJ-S may change. After the execution, write the value of ADJ-S
in the service label.
Display/adj/set range
During operation: ACTIVE, When operation finished normally: OK!
Required time
10 sec
Related service mode
COPIER> ADJUST> ADJ-XY> ADJ-S
Supplement/memo
The shading position can be adjusted manually by COPIER> ADJUST>
ADJ-XY> ADJ-S.
CARD-NUM
Setting of the first number of the card to be used
Details
To set the card first number to be used for Copy Card Reader-F1.
Use case
At installation of the Card Reader-F1
Adj/set/operate method Enter the value, and then press OK key.
Display/adj/set range
1 to 2,701
Default value
1
Related service mode
COPIER> FUNCTION> INSTALL> CARD
CARD
Setting of Card Reader management information
Details
To set the following management information at installation of the Card
Reader-F1.
- Register numbers of 300 cards from the number set in CARD-NUM to
the department ID.
- Initialize ID and password of the system administrator.
Use case
• - At installation of the Card Reader-F1
Adj/set/operate method 1) Select the item, and then press OK key.
2) Turn OFF/ON the main power switch.
Default value
0
Related service mode
COPIER> FUNCTION> INSTALL> CARD-NUM
8-80
8-80
