2.1.3

Performance

2.1.4

User Friendliness

2.1.5

Onboard Control Button

2016-04
The Infinite 200 PRO has been designed to meet the requirements of a general-
purpose laboratory instrument.
The Infinite 200 PRO provides a range of parameters for optimizing the
measurement results according to: the assay type (cell-based or homogeneous),
the microplate type, and the dispensed volumes per well and dispensing speeds.
The Infinite M200 PRO offers unparalleled flexibility in wavelength selection for
fluorescence intensity and absorbance measurements. Via software any
wavelength can be easily adjusted within the specified wavelength range. In
addition to single wavelength measurements, absorbance and fluorescence
spectra can be recorded. When running a spectrum there is no restriction due to
cut-off filters.
The Infinite F200 PRO offers high flexibility for the customization of fluorescence
and absorbance measurements; slides containing fluorescence and absorbance
interference filters are easily accessible to the user.
If the instructions given in this document are not correctly performed,
the instrument will either be damaged or the procedures will not be
performed correctly and the safety of the instrument is not guaranteed.
The Infinite 200 PRO possesses an onboard control button to control plate
movements without the need to be connected to the software. Upon pressing the
'Plate In/Out' button, the current position of the plate carrier is automatically
recognized and the plate is moved into or out of the instrument.
Figure 1: Onboard of the Infinite 200 PRO. The 'Plate In/Out' button is located in the front
right corner of the top cover.
IFU for Infinite 200 PRO No. 30052730
2. General Description
Note
Rev. No. 1.6 13
