5. Operating the Instrument
Note
When the option 'Max S/B Ratio' is used, the sample well is first
measured with optimal gain and the very same gain value is then
applied to the second measurement with the blank well. Therefore, both
signal and blank curves are directly comparable.
The z-position for each selected label can be defined manually. In the graph
window, the vertical yellow bar can be moved to the desired z-position.
Upon clicking 'Apply', the selected z-position will be automatically applied to the
i-control script and used for the subsequent measurement.
2016-04 IFU for Infinite 200 PRO No. 30052730 Rev. No. 1.6 91
