Cell application Gas sensor(s) not able to
failed. detect gas concentration due
to technical failure.
Error message Gas pressure/flow of CO2
"CO2 OUT OF too high in Manual Mode.
RANGE" 'Actual' (current) gas
concentration has exceeded
15 % (vol.).
Data cable not connected to
the gas control module
and/or Infinite 200 PRO.
Error message O2 sensor detects a value
"O2 OUT OF higher than 21%.
RANGE"
Error message Data cable not connected to
"O2 NO the gas control module
SENSOR" and/or Infinite 200 PRO.
Instrument with 'CO2'
configuration – no O2 sensor
installed.
• Target concentration is not
Acoustic signal
Display is
blinking
• 'Actual' (current) value
2016-04
reached after 20 min upon
initial activation of a mode.
deviates from target value
for more than 10 minutes
during operation.
IFU for Infinite 200 PRO No. 30052730
4. Gas Control Module (Enhanced)
Switch off heating to ventilate instrument. Switch
off-on gas control module using ON/OFF switch.
Wait for sensors to level for at least 10 min. Use
mode key to switch to Manual Mode to display the
actual CO and O gas concentration at ambient
2 2
conditions: CO (~0.2%), O
2
on ambient atmosphere, e.g. humidity).
Use the 'Mode' key to switch to 'CO2' and switch
ON the valve by pressing I/O key, monitor if the
gas concentration value changes. Switch OFF
valve for CO by pressing the 'I/O' key. Press the
2
'Mode' key to switch to 'O2' and switch ON valve
by pressing the 'I/O' key, monitor if the gas
concentration value changes. Switch OFF valve
for O by pressing the 'I/O' key.
2
If the gas concentration value does not change,
contact your local Tecan Expertline.
Valves will close automatically to stop the gas
flow. Reduce CO2 pressure with pressure
reduction valve on gas cylinder or laboratory gas
handling system. Wait until 'actual' (current) gas
concentration is below 15 % (vol.) (e.g. open
plate carrier compartment to speed the reduction
of CO2 value) before resuming.
Verify that data cable is connected to the gas
control module and/or Infinite 200 PRO
Check that the correct gas is used.
If the problem persists, contact your local Tecan
Expertline.
Verify that data cable is connected to the Gas
Control Module and/or Infinite 200 PRO.
For instruments with 'CO2' configuration,
In Manual Mode 'NO SENSOR' will appear on
display after 'O2'.
(O2 Mode and Dual Mode menus are unavailable
and not displayed.
Gas cylinder is empty or no gas supply available.
Gas supply low on pressure. Verify that sufficient
gas is available. Check gauges on the pressure
reduction valve. Check tubes. Check for leaks.
Check that the shut-off valve of the pressure
reduction valve is open.
When target value is reached, the acoustic signal
and blinking display will stop.
Rev. No. 1.6
(~20.9%) (depending
2
