Figure 24: Inner Cma Connector Mounted; Figure 25: Outer Cma Connector Attached - Oracle FS1-2 Installation Manual

Flash storage system (not racked)
Hide thumbs Also See for FS1-2:
Table of Contents

Advertisement

Figure 24: Inner CMA connector mounted

Legend
1 Slide rail
2 Inner CMA connector
3 Clip
3
Insert the outer CMA connector into the end of the right sliding rail.

Figure 25: Outer CMA connector attached

Install Component Rails
59
