Table 36: Three Sas Hbas Per Controller - Oracle FS1-2 Installation Manual

Table 35: Two SAS HBAs per Controller (continued)
DE Add Order String
number
10 2
11 3
12 4
13 1
14 2
15 3
16 4
17 1
18 2
19 3
20 4
The following table summarizes the string distribution for systems with three
SAS HBAs per Controller. A system with three SAS HBAs per Controller can
have one to 30 Drive Enclosures distributed across six strings.

Table 36: Three SAS HBAs per Controller

DE Add Order String
number
1 1
2 2
3 3
4 4
5 5
6 6
7 1
8 2
SAS HBA PCI Port on SAS
slot HBA
Slot 6 0
Slot 3 1
Slot 6 1
Slot 3 0
Slot 6 0
Slot 3 1
Slot 6 1
Slot 3 0
Slot 6 0
Slot 3 1
Slot 6 1
SAS HBA PCI Port on SAS
slot HBA
Slot 3 0
Slot 6 0
Slot 2 0
Slot 3 1
Slot 6 1
Slot 2 1
Slot 3 0
Slot 6 0
Wiring Diagrams
DE number within
string
3
3
3
4
4
4
4
5
5
5
5
DE number within
string
1
1
1
1
1
1
2
2
132
