Table 43: Controller ESM LED status and description

Icon

Drive Enclosure LED Indicators

The LED indicators on the operator panel of the Drive Enclosures provide system
status. The LED display identifies the Drive Enclosure by its numeric identifier.
The following figures show the operator panel LEDs for both types of Drive
Enclosure.
Location Name
Top Ready to
Remove
Middle Attention
Service
Required
Bottom OK/Activity
Oracle FS System LED Status
Color Status and meaning
Blue On – ESM can be
•
removed as a hot-
swap operation.
Off – Do not
•
remove the ESM.
Flashing – ESM is
•
initializing.
Amber On – Normal fault
•
is detected.
Off – No faults are
•
detected.
Flashing – No
•
function.
Green On – ESM is
•
functional without
fault.
Off – ESM is off or
•
initializing.
Flashing – ESM
•
read and write
activity.
203
