Prepare for System Installation

Prepare for Installation

Component Placement

Oracle recommends the following rack unit (RU) locations for installing the
components in the rack:

Table 16: Default component placement in racks

Component type
Drive Enclosures
Pilot-1
Pilot-2
Controller-1
Controller-2
Remaining Drive Enclosures
If the Oracle FS System includes one Replication Engine, then follow the
placement shown in the following table:

Table 17: Component placement with one Replication Engine

Component type
Drive Enclosures
Replication Engine-1
Pilot-0
Pilot-1
Controller-1
RU space for installation
RU 1 to RU 20
RU 21
RU 22
RU 23, RU 24
RU 25, RU 26
RU 27 to RU 42
RU space for installation
RU 1 to RU 18
RU 19, RU 20
RU 21
RU 22
RU 23, RU 24
RU space if a DE2-24C
DE follows RU 18
RU 1 to RU 18
RU 19
RU 20
RU 21, RU 22
RU 23, RU 24
RU 25 to RU 28 (next
DE2-24C DE)
RU 29 to RU 42
RU space if a DE2-24C
DE follows RU 16
RU 1 to RU 16
RU 17, RU 18
RU19
RU20
RU 21, RU22
