Legend
4
Remove the front-side caps on both sides of the Drive Enclosure and secure
a Phillips 13mm head hex flange screw.
Note: The front-side cap on the right side of the Drive Enclosure contains
the RFID tag, which uniquely identifies the Drive Enclosure. Take care not
to mix up the right front-side caps among Drive Enclosures.
Figure 51: Left front-side cap and Phillips 13mm head hex flange screw
Legend
After you have secured the Drive Enclosure to the rails, attach the front-
side caps to the Drive Enclosure.
5
Insert the I/O modules, the power cooling modules, and all of the drives
into their corresponding slots in the chassis.
Insert a DE2-24P Drive Enclosure Into a Rack
1
Carefully lift the Drive Enclosure to the location of the prepared slot and
rest the Drive Enclosure on the bottom ledge of the left and right rails.
Caution:
1 Phillips Number 2 pan head screw with patch lock
1 Phillips 13mm head hex flange screw
The DE2-24C Drive Enclosure weighs approximately 102 lbs (46 kg).
•
The DE2-24P Drive Enclosure weighs approximately 53 lbs (24 kg).
Use a mechanical lift when handling fully populated Drive
Enclosures.
If you are working alone or you do not have access to a mechanical
•
lift, you can reduce the weight of a Drive Enclosure by removing the
drives, the I/O modules, and the power cooling modules from the
chassis. An empty DE2-24C Drive Enclosure chassis weighs
Install Components into the Rack
2 Left front-side cap
83
