Figure 55: Controller slide rails unlocked
Legend
1 Slide rail assembly
2 Slide rail lock button
2
Inspect the attached cables for any binding or kinks.
3
Verify that the CMA extends fully and does not bind in the slide rails.
4
When the Controller is fully extended out, release the mounting bracket
release button.
Figure 56: Mounting bracket release button
Install Components into the Rack
88
