Table 28: Mini-SAS HD cables
Cable
Color
Mini-SAS
Black
HD to mini-
SAS HD
The following figure shows an example of mini-SAS HD to mini-SAS HD cable
connectors.
Figure 67: Example of mini-SAS HD to mini-SAS HD cable connectors
SAS Cables for Drive Enclosure-to-Controller Connections
The following table lists the types of mini-SAS to mini-SAS HD cables and the
lengths of the cables used to connect Drive Enclosures to Controllers.
Table 29: Mini-SAS to mini-SAS HD cables
Cable
Color
Mini-SAS to
Black
mini-SAS
HD
Mini-SAS to
Black
mini-SAS
HD
Cable path
Quantity
Connects Controller
1 to Controller 2
Cable path
Quantity
Connects a
Controller to a
Drive Enclosure in
the same rack
Connects a
Controller to a
Drive Enclosure
that is in a separate
rack
Oracle FS System Cables
Cable length
Two for a base
9.84 feet
system with one
(3 m)
SAS HBA installed
Four for a base
system with two
SAS HBAs installed
Six for a
performance system
Cable length
Varies based on the
9.84 feet
configuration of the
(3 m)
system
Varies based on the
19.69 feet
configuration of the
(6 m)
system
106
