Controller ESM LED Indicators
Three LEDs represent the status of each energy storage module (ESM). The LEDs
are above the release button of each drive.
Figure 104: Controller drive LEDs
Legend
1 Ready to Remove LED
2 Attention Service Required LED
This following table describes the functionality of the ESM LEDs:
Oracle FS System LED Status
3 OK/Activity LED
