Table 34: One SAS HBA per Controller

DE Add Order String
number
1 1
2 2
3 1
4 2
5 1
6 2
7 1
8 2
9 1
10 2
The following table summarizes the string distribution for systems with two SAS
HBAs per Controller. A system with two SAS HBAs per Controller can have one
to 20 Drive Enclosures distributed across four strings.

Table 35: Two SAS HBAs per Controller

DE Add Order String
number
1 1
2 2
3 3
4 4
5 1
6 2
7 3
8 4
9 1
SAS HBA PCI Port on SAS
slot HBA
Slot 3 0
Slot 3 1
Slot 3 0
Slot 3 1
Slot 3 0
Slot 3 1
Slot 3 0
Slot 3 1
Slot 3 0
Slot 3 1
SAS HBA PCI Port on SAS
slot HBA
Slot 3 0
Slot 6 0
Slot 3 1
Slot 6 1
Slot 3 0
Slot 6 0
Slot 3 1
Slot 6 1
Slot 3 0
Wiring Diagrams
DE number within
string
1
1
2
2
3
3
4
4
5
5
DE number within
string
1
1
1
1
2
2
2
2
3
