Oracle FS1-2 Installation Manual page 200

Table 40: Controller LED status and description (back panel) (continued)
No. LED
3
Network
management LED
4
Net0 to Net3
status LEDs
LED color Status
Indicates these conditions:
(Left) Link
•
and
Activity
LED:
Green
(Right)
•
Speed
LED:
Green,
amber, or
OFF
(Left) Link Indicates the state of the service
•
and processor:
Activity
LED:
Green
(Right)
•
Speed
LED:
Amber
Oracle FS System LED Status
Link and Activity LED:
•
On or blinking – A link
•
is established.
Off – No link is
•
established.
Speed LED:
•
On or blinking – The
•
link is operating as a
100-Mbps connection.
Off – The link is
•
operating as a 10-Mbps
connection.
Link and Activity LED:
•
On or blinking – A link
•
is established.
Off – No link is
•
established.
Speed LED:
•
Amber – The link is
•
operating as a Gigabit
connection (1000-
Mbps).
Green – The link is
•
operating as a 100-
Mbps connection.
Off – The link is
•
operating as a 10-Mbps
connection or there is
no link.
