Figure 105: Operator panel LEDs (DE2-24P Drive Enclosure)
Legend
1 System power indicator
2 Module fault indicator
Figure 106: Operator panel LEDs (DE2-24C Drive Enclosure)
Legend
1 System power indicator
2 Module fault indicator
The following table provides status information on the operator panel LEDs.
Oracle FS System LED Status
3 Locate indicator and logical fault
indicator
4 Chassis ID
3 Locate indicator and logical fault
indicator
4 Chassis ID
