Page 1 Oracle ZFS Storage Appliance ® Installation Guide, Release OS8.8.x Part No: F13767-07 August 2021...
Page 3 Oracle. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services, except as set forth in an applicable agreement between you and Oracle.
Page 4 For information about Oracle's commitment to accessibility, visit the Oracle Accessibility Program website at http://www.oracle.com/pls/topic/lookup?ctx=acc&id=docacc. Access to Oracle Support Oracle customers that have purchased support have access to electronic support through My Oracle Support. For information, visit http://www.oracle.com/pls/topic/lookup? or visit if you are hearing impaired.
Page 5 Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers, sauf mention contraire stipulée dans un contrat entre vous et Oracle. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des dommages causés par l'accès à...
Page 6 Contrat-Cadre Oracle (OMA), Contrat de Licence et de Services Oracle (OLSA), Contrat Réseau Partenaires Oracle (OPN), contrat de distribution Oracle ou de tout autre contrat de licence en vigueur que vous avez signé et que vous vous engagez à respecter. Ce document et son contenu ne peuvent en aucun cas être communiqués, copiés, reproduits ou distribués à...
Page 7: Table Of Contents
Cable Bend Radius ................ 20 Supported Disk Shelf Combinations and HBAs ........... 21 Maximum Disk Shelves per Controller Configuration .......... 22 Overview of Disk Shelves ................ 25 Oracle Storage Drive Enclosure DE3-24 ............ 25 Oracle Storage Drive Enclosure DE2-24 ............ 33 Sun Disk Shelf .................. 39 Disk Shelf Components ................ 43 Overview of ZS9-2 Controller .................
Page 8 ZS3-2 Physical Specifications .............. 70 ZS3-2 Electrical Specifications .............. 70 ZS3-2 Acoustic Noise Emissions .............. 71 ZS3-2 Configuration Options .............. 71 ZS3-2 Front Panel Components ............... 71 ZS3-2 Rear Panel Components .............. 72 Optional Cable Management Arm ............ 75 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 9 Contents Overview of 7420 Controller ................ 76 7420 Physical Specifications .............. 76 7420 Electrical Specifications .............. 76 7420 Configuration Options .............. 77 7420 Front Panel Components .............. 78 7420 Rear Panel Components .............. 79 Overview of 7320 Controller ................ 80 7320 Electrical Specifications .............. 81 7320 Base Configurations ............... 81 7320 Front Panel Components ..............
Page 10 ▼ Installing the Mounting Brackets on a 7x20 .......... 205 ▼ Installing a 7x20 onto the Rack Slide Rails .......... 207 ▼ Installing a 7x20 Cable Management Arm ........... 212 Cabling the Appliance .................. 219 ▼ Connecting System Cables ............... 219 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 11 ▼ Powering Off a Disk Shelf ............... 235 Configuring the Appliance for the First Time .......... 237 ▼ Configuring the System ................ 238 ▼ Performing Initial Configuration (BUI) ............ 241 ▼ Performing Initial Configuration (CLI) ............ 256 Troubleshooting Hardware Faults .............. 265 ▼ Connecting to Oracle ILOM .............. 265...
Page 12 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 13: Installation Overview
Installation Overview This guide describes installation procedures for Oracle ZFS Storage Appliance. Each controller should have at least one NIC port configured as a management interface. If necessary, install additional NIC card(s) into the appropriate PCIe slot(s) before initial controller installation. For information on installing a PCIe card, see the appropriate section for...
Page 14 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 15: Installation Prerequisites And Hardware Overviews
Installation Prerequisites and Hardware Overviews This section gives an overview of the Oracle ZFS Storage Appliance disk shelves and controllers, as well as the prerequisites for installation. For safety information and configuration guidelines, see: “Prerequisites for Installation” on page 15 ■...
Page 16: Security Information
“Cabinet and Tool Requirements” on page 16 ■ “Disconnecting an RJ-45 Cable” on page 18 ■ Security Information To understand the security issues relevant to initial installation of the Oracle ZFS Storage Appliance, refer to the Oracle ZFS Storage Appliance Security Guide, Release OS8.8.x. Safety Information Take the following precautions when installing disk shelves and controllers into a rack.
Page 17 Note - power supply with fan modules to reduce the weight. For instructions, refer to “Servicing the Disk Shelves” in Oracle ZFS Storage Appliance Customer Service Manual. A flashlight for the spotter to ensure the shelf is engaged in the rails.
Page 18: Disconnecting An Rj-45 Cable
Using your thumb and middle finger, apply a slight downward pressure while pulling the plug out of the port. Do not pull the plug upward or pinch the release tab with your fingers below the plug, as shown below. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 19: Cabinet Configuration Guidelines
For safety reasons, mount the heaviest equipment, typically disk shelves, at the bottom ■ of the cabinet. Refer to the appropriate Oracle Safety and Compliance Guide for rack- mounting guidelines. To best prepare for cabling controllers to disk shelves, now and in the future, mount ■...
Page 20: Cable Lengths
DE2-24 disk shelves with specific drive types (see “Cabling Mixed DE3-24 and DE2- ■ 24 Disk Shelves to ZS9-2 High-end (HE) Controllers” in Oracle ZFS Storage Appliance Cabling Guide are supported by ZS9-2 controllers and require SAS copper cabling connections. DE2-24 disk shelf connection to ZS7-2 controllers is supported in software release OS8.8.4 and later.
Page 21: Supported Disk Shelf Combinations And Hbas
DE2-24 and Sun Disk Shelf together SAS-2 4x4 port HBA SAS-2 2x4 port HBA for only Sun ZFS Storage 7120 The following table describes which disk shelf models can be used together for which controller configurations, starting with software release OS8.7.0. DE2-24 disk shelf connection to ZS7-2 controllers is supported in software release OS8.8.4 and later.
Page 22: Maximum Disk Shelves Per Controller Configuration
HBA type. Supported Disk Shelf Chains per HBA TABLE 3 HBA Type Number of Disk Shelf Chains per HBA SAS-3 4x4 port SAS-2 4x4 port Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 23 Maximum Disk Shelves per Controller Configuration HBA Type Number of Disk Shelf Chains per HBA SAS-2 2x4 port As of software release OS8.7.0, 4x4 port SAS-3 HBAs and 4x4 port SAS-2 HBAs can be used together in the same system. Controllers cannot simultaneously use 2x4 port SAS-2 HBAs and 4x4 port SAS-2 HBAs.
Page 24 (DE2 and legacy Sun Disk Shelves) to the same controllers, but each chain must contain only the same disk shelf type. Directly connecting different disk shelf types is not supported. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 25: Overview Of Disk Shelves
(DE2 and legacy Sun Disk Shelves) to the same controllers. Overview of Disk Shelves This section provides an overview of the Oracle ZFS Storage Appliance disk shelves. For installation instructions, refer to “Installing Disk Shelves” on page 89.
Page 26 Read-optimized cache SSDs can also be installed in the DE3-24P disk shelf, for some controllers. For slot configuration details and minimum software requirements, see “Disk Shelf Configurations” in Oracle ZFS Storage Appliance Customer Service Manual. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 27 Overview of Disk Shelves DE3-24P Status Indicators (Front View) FIGURE 2 Figure Legend 1 Locate indicator 2 Service required indicator 3 OK indicator 4 Power supply fault indicator 5 SAS I/O Module fault indicator 6 Power/Activity indicator 7 Drive service required indicator 8 Ready-to-remove indicator Installation Prerequisites and Hardware Overviews...
Page 28 4 Power supply with fan module 1 DE3-24C Disk Shelf The Oracle Storage Drive Enclosure DE3-24C is a 4U chassis that supports 24 3.5" SAS-3 drives. The high-performance HDDs provide reliable storage. The SSDs provide accelerated write operations, and for some controllers, read-optimized cache operations. This disk shelf features dual, redundant I/O Modules (IOMs), and dual power supply with fan modules.
Page 29 Read-optimized cache SSDs can also be installed in the DE3-24C disk shelf, for some controllers. For slot configuration details and minimum software requirements, see “Disk Shelf Configurations” in Oracle ZFS Storage Appliance Customer Service Manual. Installation Prerequisites and Hardware Overviews...
Page 30 2 Service required indicator 3 OK indicator 4 Power supply fault indicator 5 SAS I/O Module fault indicator 6 Ready-to-remove indicator 7 Drive service required indicator 8 Power/Activity indicator Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 31 Overview of Disk Shelves DE3-24C Rear Panel FIGURE 6 Figure Legend 1 Power supply filler panel, slot 4 2 I/O Module 1 3 I/O Module filler panel 4 Power supply with fan module 2 5 Power supply filler panel, slot 2 6 I/O Module filler panel 7 I/O Module 0 8 Power supply with fan module 1...
Page 32 10 Host port activity indicator 11 Power/Activity indicator 12 I/O Module service required indicator 13 Ready-to-remove indicator 14 For Oracle service only The DE3-24C and DE3-24P disk shelves use the same I/O Module. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 33: Oracle Storage Drive Enclosure De2-24
DE2-24 Disk Shelf The Oracle Storage Drive Enclosure DE2-24P is a 2U chassis that supports 24 2.5" SAS-2 drives. The high-capacity HDDs provide reliable storage. The SSDs provide accelerated write operations, and for some controllers, read-optimized cache operations. This disk shelf features dual, redundant I/O Modules (IOMs), and dual power supply with fan modules.
Page 34 Configurations” in Oracle ZFS Storage Appliance Customer Service Manual. FIGURE 10 DE2-24P Status Indicators (Front View) Figure Legend 1 System power indicator 2 Module fault indicator 3 Locate indicator 4 Power/Activity indicator 5 Drive fault indicator Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 35 4 Power supply with fan module 1 DE2-24C Disk Shelf The Oracle Storage Drive Enclosure DE2-24C is a 4U chassis that supports 24 3.5" SAS-2 drives. The high-capacity HDDs provide reliable storage. The SSDs provide accelerated write operations, and for some controllers, read-optimized cache operations. This disk shelf features dual, redundant I/O Modules (IOMs), and dual power supply with fan modules.
Page 36 Read-optimized cache SSDs can also be installed in the DE2-24C disk shelf, for some controllers. For slot configuration details and minimum software requirements, see “Disk Shelf Configurations” in Oracle ZFS Storage Appliance Customer Service Manual. FIGURE 13 DE2-24C Status Indicators (Front View) Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 37 Overview of Disk Shelves Figure Legend 1 System power indicator 2 Module fault indicator 3 Locate indicator 4 Power/Activity indicator 5 Drive fault indicator FIGURE 14 DE2-24C Rear Panel Figure Legend 1 Power supply filler panel, slot 0 2 Power supply with fan module 1 3 Power supply with fan module 2 4 Power supply filler panel, slot 3 5 I/O Module filler panel...
Page 38 6 Host port activity indicators 7 For Oracle service only 8 For Oracle service only The DE2-24C and DE2-24P disk shelves use the same I/O Module. FIGURE 16 DE2 Power Supply Indicators Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 39: Sun Disk Shelf
Overview of Disk Shelves Figure Legend 1 DC power fail indicator 2 Fan fail indicator 3 AC power fail indicator 4 Power supply status indicator 5 Power on/off switch 6 Universal power input connector 7 Power cord tie wrap The DE2-24C and DE2-24P disk shelves use the same power supply. Sun Disk Shelf The Sun Disk Shelf is a 4U chassis that supports 24 3.5"...
Page 40 4 Disk ready to be removed indicator 5 Disk fault indicator 6 Disk activity indicator 7 Over temperature warning 8 SIM board fault indicator 9 Power supply fault indicator indicator Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 41 Overview of Disk Shelves Sun Disk Shelf Rear Panel FIGURE 19 Figure Legend 1 Power supply modules with built-in fans. Power supply 2 Removable SAS Interface Module (SIM) Boards. SIM 0 is on the left and power supply 1 is on the right. 0 is on the left, and SIM 1 is on the right.
Page 42 5 Universal power connector 6 Power switch 7 Port fault indicator 8 Port OK indicator 9 SIM board OK indicator (green)/ SIM board fault indicator (amber) 10 SIM locator indicator Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 43: Disk Shelf Components
7 Universal power input connector 8 Right ejection arm and captive screw latch Disk Shelf Components The following sections describe each disk shelf's components: Oracle Storage Drive Enclosure DE3-24P Components Drive Enclosure DE3-24P Base Chassis ■ Filler Panel, Drive Enclosure DE3-24P ■...
Page 44: Overview Of Zs9-2 Controller
■ Up to 24 3.5" SAS-2 HDDs, SSDs ■ Overview of ZS9-2 Controller This section provides an overview of the Oracle ZFS Storage ZS9-2 controller. For installation instructions, refer to “Installing a ZS9-2 Controller” on page 115. For service instructions, refer to “Servicing the ZS9-2 Controller”...
Page 45: Zs9-2 Electrical Specifications
Overview of ZS9-2 Controller ZS9-2 Electrical Specifications The ZS9-2 controller has two hot-swappable rear accessible power supplies with N+N redundancy. To understand the overall power consumption, see Oracle's online power calculator at http://www.oracle.com/goto/powercalculators. Parameter AC Power Supplies Nominal input frequencies...
Page 46: Zs9-2 Front Panel Components
The most recent component specification is located at https://www.oracle.com/storage/ nas/index.html. ZS9-2 Front Panel Components The ZS9-2 controller drive slots and front panel components are shown in the following figure. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 47 Overview of ZS9-2 Controller ZS9-2 Front Panel FIGURE 22 1 RFID tag 2 System status LED: Locator 3 System status LED: Service Action (white) Required (amber) 4 System status LED: Power/OK 5 Power button 6 Fan service action required (amber) (green) 7 Power Supply (PS) service action 8 Over-temperature warning (amber)
Page 48: Zs9-2 Rear Panel Components
15 System status LEDs: T RJ-45 Gigabit Ethernet (GbE) port: ■ Locate (white) - left NET 0 ■ Attention (amber) - right, top ■ Power/OK (green) - right, bottom Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 49: Overview Of Zs7-2 Controller
For information about how to connect cables to form a cluster, see “Connecting Cluster Cables” on page 220. Overview of ZS7-2 Controller This section provides an overview of the Oracle ZFS Storage ZS7-2 controller. For installation instructions, refer to “Installing a ZS7-2 Controller” on page 131. For service instructions, refer to “Servicing the ZS7-2 Controller”...
Page 50: Zs7-2 Acoustic Noise Emissions
Memory System Disks PCIe Slots 2x18-core, 2.3 GHz 512 GB or 1024 GB 2x3.5'' SAS-3 Four dedicated; 4-port (4x4) SAS-3 five available; 12 Gb/s external two unavailable Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 51: Zs7-2 Front Panel Components
System Disks PCIe Slots (permanent filler panels) The most recent component specification is located at https://www.oracle.com/storage/ nas/index.html. ZS7-2 Front Panel Components The ZS7-2 controller drive slots and front panel components are shown in the following figure. FIGURE 24 ZS7-2 Front Panel...
Page 52: Zs7-2 Rear Panel Components
■ Power/OK (green) 4 PSU 0 status indicators (top to 5 Fifth PCIe option (slot 1) 6 External SAS-3 HBA (slot 2) bottom): ■ Attention (amber) ■ Power/OK (green) Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 53: Overview Of Zs5-4 Controller
For information about how to connect cables to form a cluster, see “Connecting Cluster Cables” on page 220. Overview of ZS5-4 Controller This section provides an overview of the Oracle ZFS Storage ZS5-4 controller. For installation instructions, refer to “Installing a ZS5-4 Controller” on page 147. For service instructions, refer to “Servicing the ZS5-4 Controller”...
Page 54: Zs5-4 Electrical Specifications
Weight (Maximum) 88 lb./40 kg ZS5-4 Electrical Specifications The ZS5-4 controller has two hot-swappable rear accessible power supplies with N+N redundancy. To understand the overall power consumption, see Oracle's online power calculator at http://www.oracle.com/goto/powercalculators. Parameter AC Power Supplies Nominal input frequencies...
Page 55: Zs5-4 Front Panel Components
Overview of ZS5-4 Controller The most recent component specification is located at https://www.oracle.com/storage/ nas/index.html. ZS5-4 Front Panel Components The ZS5-4 controller drive slots and front panel components are shown in the following figure. FIGURE 26 ZS5-4 Front Panel 1 LEDs (left to right)
Page 56: Zs5-4 Rear Panel Components
PCIe (slot 3) 19 System status LEDs (left to right) 20 PSU 1 AC inlet 21 PSU 0 AC inlet ■ Power/OK (green) ■ Attention (amber) ■ Locate (white) Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 57: Overview Of Zs5-2 Controller
For information about how to connect cables to form a cluster, see “Connecting Cluster Cables” on page 220. Overview of ZS5-2 Controller This section provides an overview of the Oracle ZFS Storage ZS5-2 controller. For installation instructions, refer to “Installing a ZS5-2 Controller” on page 157. For service instructions, refer to “Servicing the ZS5-2 Controller”...
Page 58: Zs5-2 Acoustic Noise Emissions
Gb/s external Refer to https://oracle.com/zfsstorage for the most recent component specification. ZS5-2 Front Panel Components The ZS5-2 controller drive slots and front panel components are shown in the following figure. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 59: Zs5-2 Rear Panel Components
Overview of ZS5-2 Controller ZS5-2 Front Panel FIGURE 28 1 LEDs: Locator, Service, Power 2 System disk 1 3 Permanent HDD filler panels 4 Two USB 2.0 ports 5 RFID tag 6 System disk 0 7 Alarm indicators (not used) ZS5-2 Rear Panel Components The ZS5-2 controller PCIe slots and rear panel components are shown in the following figure.
Page 60: Cable Management Arm
220. Cable Management Arm The following figure identifies the components of the cable management arm (CMA). For installation instructions, see “Installing a ZS5-2 Cable Management Arm” on page 164. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 61 Overview of ZS5-2 Controller ZS5-2 Controller Cable Management Arm FIGURE 30 Figure Legend Connector A Connector D Front slide bar Slide-rail latching bracket (used with connector D) Velcro straps (6) Rear slide bar Connector B Cable covers Connector C Installation Prerequisites and Hardware Overviews...
Page 62: Overview Of Zs4-4 Controller
Overview of ZS4-4 Controller Overview of ZS4-4 Controller This section provides an overview of the Oracle ZFS Storage ZS4-4 controller. For installation instructions, refer to “Installing a ZS4-4 or ZS3-4 Controller” on page 175. For service instructions, refer to “Servicing the ZS4-4 Controller” in Oracle ZFS Storage Appliance Customer Service Manual.
Page 63: Zs4-4 Rear Panel Components
The ZS4-4 rear panel is shown in the following figure. Base configuration PCIe cards are not depicted in this illustration. For more information about PCIe cards, see “ZS4-4 PCIe I/O Cards” in Oracle ZFS Storage Appliance Customer Service Manual. Installation Prerequisites and Hardware Overviews...
Page 64 Use these ports to connect the appliance to the network. The LEDs located above the NET ports, labeled 2, 0, 3, 1 (left to right) are Link/Activity indicators. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 65 Overview of ZS4-4 Controller Status OFF (1) No Link ON (0) Link and no activity Blink Link and activity Speed is not indicated for the NET ports. Note - Network Management Port - The network management connector (NET MGT) is an RJ- ■...
Page 66: Overview Of Zs3-4 Controller
Overview of ZS3-4 Controller Overview of ZS3-4 Controller This section provides an overview of the Oracle ZFS Storage ZS3-4 controller. For installation instructions, refer to “Installing a ZS4-4 or ZS3-4 Controller” on page 175. For service instructions, refer to “Servicing the ZS3-4 Controller” in Oracle ZFS Storage Appliance Customer Service Manual.
Page 67: Zs3-4 Front Panel Components
Overview of ZS3-4 Controller ZS3-4 Front Panel Components ZS3-4 Front Panel FIGURE 34 Figure Legend 1 Locator LED and button (white) 2 Service Required LED (amber) 3 Power/OK LED (green) 4 Power button 5 Service Processor (SP) OK LED 6 Fan/CPU/Memory Service (green) Required LED 7 Power Supply (PS) Service...
Page 68: Zs3-4 Rear Panel Components
For information about PCIe cards, see “ZS3-4 PCIe I/O Cards” in Oracle ZFS Storage Appliance Customer Service Manual. FIGURE 36 ZS3-4 Rear Panel Components Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 69 Overview of ZS3-4 Controller Figure Legend 1 Power supply unit 0 status LEDs 2 Power supply unit 0 AC inlet 3 Power supply unit 1 status LEDs OK: green Power Supply Fail: amber OK: green Power Supply Fail: amber AC OK: green AC OK: green 4 Power supply unit 1 AC inlet 5 System status LEDs Power: green...
Page 70: Overview Of Zs3-2 Controller
Overview of ZS3-2 Controller Overview of ZS3-2 Controller This section provides an overview of the Oracle ZFS Storage ZS3-2 controller. For installation instructions, refer to “Installing a ZS3-2 Controller” on page 185. For service instructions, refer to “Servicing the ZS3-2 Controller” in Oracle ZFS Storage Appliance Customer Service Manual.
Page 71: Zs3-2 Acoustic Noise Emissions
512GB 16x32GB 4-port (4x4) SAS-2 6Gb/s external Refer to https://oracle.com/zfsstorage for the most recent component specification. ZS3-2 Front Panel Components The ZS3-2 controller drive slots and front panel components are shown in the following figure. Installation Prerequisites and Hardware Overviews...
Page 72: Zs3-2 Rear Panel Components
The ZS3-2 controller PCIe slots and rear panel components are shown in the following figure. For more information about PCIe cards, see “ZS3-2 PCIe I/O Cards” in Oracle ZFS Storage Appliance Customer Service Manual. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 73 Overview of ZS3-2 Controller ZS3-2 Controller Rear Panel FIGURE 38 Figure Legend 1 SAS-2 internal HBA (slot 1) 2 4x4 SAS external HBA (slot 2) 3 PCIe slot 3 4 PCIe slot 4 5 PCIe slot 5 6 PCIe slot 6 7 AC power supplies PS1 (top), PS0 8 System status LEDs 9 USB 2.0 ports...
Page 74 HBA Ports - The 4x4 SAS HBA, installed in PCIe slot 2 of the ZS3-2, provides ■ connectivity to external disk shelves. The HBA logical ports are numbered 0-3, left to right, as shown below: Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 75: Optional Cable Management Arm
Overview of ZS3-2 Controller Optional Cable Management Arm The following figure identifies the components of the second-generation cable management arm (CMA). See the CMA installation instructions. Cable Management Arm Components FIGURE 39 Figure Legend 1 Connector A 2 Front slide bar 3 Velcro straps (6) Installation Prerequisites and Hardware Overviews...
Page 76: Overview Of 7420 Controller
8 Rear slide bar 9 Cable covers with connector D) Overview of 7420 Controller This section provides an overview of the Oracle ZFS Storage 7420 controller. For installation instructions, refer to “Installing a 7x20 Controller” on page 203. For service instructions, refer to “Servicing the 7420 or 7320 Controller”...
Page 77: 7420 Configuration Options
Volt-Ampere rating: 1837 VA @ 240 VAC, 0.98 P.F. ■ 7420 Configuration Options The Sun ZFS Storage 7420 Appliance consists of a standalone storage controller, or two storage controllers in a high-availability cluster configuration, and one to 36 disk shelves. The following table describes the 7420 configuration options: 7420 M2 controllers cannot be clustered with 7420 controllers.
Page 78: 7420 Front Panel Components
Zero, two, three, or four read cache SSDs, may optionally fill slots 2 through 5, in order. In a 7420 cluster, the number of SSDs installed in both controllers must match. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 79: 7420 Rear Panel Components
The following graphic shows the rear panel of the controller. Base configuration HBAs are not depicted in this illustration. For information about PCIe cards, see “7420 PCIe I/O Cards” in Oracle ZFS Storage Appliance Customer Service Manual. Installation Prerequisites and Hardware Overviews...
Page 80: Overview Of 7320 Controller
MGT) 10/100 BASE-T Ethernet port port 13 DB-15 video connector Overview of 7320 Controller This section provides an overview of the Oracle ZFS Storage 7320 controller. For installation instructions, refer to “Installing a 7x20 Controller” on page 203. For service instructions, refer to “Servicing the 7420 or 7320 Controller”...
Page 81: 7320 Electrical Specifications
Overview of 7320 Controller 7320 Electrical Specifications The following list shows the electrical specifications for the 7320 controller. The power dissipation numbers listed are the maximum rated power numbers for the Note - power supply. The numbers are not a rating of the actual power consumption of the appliance. Connectors Two C13 connectors, which work on 110-220v outlets ■...
Page 82: 7320 Front Panel Components
(ReadZilla SSDs), which store the read cache, fill slots 2 through 5, in order. Slots 6 and 7 are empty and must contain drive fillers. FIGURE 44 7320 Front Panel Drive Locations Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 83: 7320 Rear Panel Components
Following is an illustration of the 7320 storage controller rear panel. The Sun 375-3609 belongs in slot 2, cannot be installed in any other slots, and a second is not offered as an option. For information about PCIe cards, see “7320 Configuration Options” in Oracle ZFS Storage Appliance Customer Service Manual.
Page 84: Overview Of 7120 Controller
■ connector and is a terminal connection to the SP console. Overview of 7120 Controller This section provides an overview of the Oracle ZFS Storage 7120 controller. For installation instructions, refer to “Installing a 7x20 Controller” on page 203. For service instructions,...
Page 85: 7120 Front Panel Components
Overview of 7120 Controller Nominal frequencies: 50/60Hz ■ Nominal voltage range: 100-120/200-240 VAC ■ Maximum current AC RMS: 13.8A @ 100 VAC ■ AC operating range: 90-264 VAC ■ Output 3.3 VDC STBY: 3.0A ■ +12 VDC: 86.7A ■ Power dissipation Max power consumption: 1235.3 W ■...
Page 86: 7120 Rear Panel Components
11 Network Management port 12 Gbit Ethernet ports NET 0, 1, 2, 3 13 USB 2.0 ports (0, 1) 14 HD15 Video port The 7120 controller has the following ports: Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 87 Overview of 7120 Controller Ethernet Ports - There are four RJ-45 Gigabit Ethernet ports (NET 0, NET 1, NET 2, ■ NET 3) located on the motherboard that operate at 10/100/1000 Mbit/sec. These network interfaces must be configured before use. Network Management Port - The network management connector (NET MGT) is an RJ- ■...
Page 88 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 89: Installing Disk Shelves
“Installing a Sun Disk Shelf” on page 109 ■ Installing a DE3-24P Disk Shelf The Oracle Storage Drive Enclosure DE3-24P requires two rack units (RU), or six rack holes, of vertical space in the cabinet. Review “Prerequisites for Installation” on page 15 “Overview of Disk...
Page 90 Adjust the rail length to fit the front and rear of the rack [A and B]. Mark which rack rail holes you will be using to ensure the shelf rails are installed evenly. Note - Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 91 Installing a DE3-24P Disk Shelf Press and hold open the clamp lever on each rail end [1], and insert both rail ends into the appropriate rack holes [2]. Close the rail clamps over the rails by releasing the clamp lever [3]. You will hear an audible click as the clamps lock in place over the rack rails.
Page 92 Carefully slide the disk shelf into the cabinet. Ensure that it is fully seated within the rails. If removing the disk shelf to reseat it, support it at all times. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 93: Installing A De3-24C Disk Shelf
If shipping the racked disk shelf, install a screw [1 and 2] into each rear chassis ear [A]. Installing a DE3-24C Disk Shelf The Oracle Storage Drive Enclosure DE3-24C requires four rack units (RU), or twelve rack holes, of vertical space in the cabinet. Review “Prerequisites for Installation”...
Page 94 Orient the rail so that the stamped label (LEFT or RIGHT) is facing the inside of the rack. Adjust the rail length to fit the front and rear of the rack [A and B]. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 95 Installing a DE3-24C Disk Shelf Mark which rack rail holes you will be using to ensure the shelf rails are installed evenly. Note - Press and hold open the clamp lever on each rail end [1], and insert both rail ends into the appropriate rack holes [2].
Page 96 Install the front cage nuts. A mounted disk shelf is unstable if the front cage nuts are not installed. Always Caution - install the cage nuts before mounting the disk shelf. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 97 Installing a DE3-24C Disk Shelf Use the template to determine cage nut placement [1]. Insert one cage nut into the appropriate hole in each rack rail [2]. Installing Disk Shelves...
Page 98 If removing the disk shelf to reseat it, support it at all times. Secure the front of the disk shelf using the four captive screws [1 - 4]. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 99: Installing A De2-24P Disk Shelf
If shipping the racked disk shelf, install a screw [1 and 2] into each rear chassis ear [A]. Installing a DE2-24P Disk Shelf Use the following procedure to install an Oracle Storage Drive Enclosure DE2-24P, which requires two standard mounting rack units (2RU), or six rack holes, of vertical space in the cabinet.
Page 100 Insert and tighten one screw through the front of the rack and into the top hole in the rails. Adjust the rail lengths to fit, and position the rear rail location pegs in the corresponding rear rack holes. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 101 Installing a DE2-24P Disk Shelf Insert and tighten one screw through the back of the rack and into the back of the rails. If your rack is a threaded universal 19-inch cabinet: Installing Disk Shelves...
Page 102 Adjust the rail lengths to fit, and locate the rear pins inside the corresponding rear rack holes. Insert and tighten one screw through the back of the rack and into the back of the rails. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 103 Installing a DE2-24P Disk Shelf Using a mechanical lift or two people, one at each side of the disk shelf, carefully lift and rest the shelf on the bottom ledge of the left and right rails. Do not lift using the power supply with fan module handles. Carefully slide the shelf into the rails until it is fully seated within the cabinet.
Page 104: Installing A De2-24C Disk Shelf
Remove the front side caps, install one screw into each front side, and replace the caps. Installing a DE2-24C Disk Shelf Use the following procedure to install an Oracle Storage Drive Enclosure DE2-24C, which requires four standard mounting rack units (4RU), or twelve rack holes, of vertical space in the cabinet.
Page 105 Locate the appropriate rack unit (RU) height, which is eight rack holes, starting from the bottom on the cabinet. If using an unthreaded universal 19-inch, Sun Rack II, or Oracle Rack Cabinet 1242 cabinet, snap one supplied cage nut into the appropriate rack holes.
Page 106 Do not install into the cage nut in the rack, or the clip nut on the rail. Threaded cabinet - The location pins fit inside the rack holes. ■ Adjust the rail lengths to fit. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 107 Installing a DE2-24C Disk Shelf Install one screw through the rack and into the rear of each rail. Tighten the two locking screws in the rails. Installing Disk Shelves...
Page 108 If removing the shelf to reseat it, support it at all times. Remove the front side caps, install two screws into each front side, and replace the caps. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 109: Installing A Sun Disk Shelf
Installing a Sun Disk Shelf Install one long patchlock screw per rail to secure the rear of the shelf to the rear of the rack. Installing a Sun Disk Shelf Use the following procedure to install a Sun Disk Shelf. Starting at the bottom of the cabinet, locate the appropriate rack unit (RU) height.
Page 110 Install appropriate rail plates in four locations on the rack (2 front and 2 back) by aligning the two pins on the rail plate with holes on the cabinet rails. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 111 Installing a Sun Disk Shelf Insert M6 screws in the top and bottom holes of each rail plate and tighten (8 total places). Install each rail by first aligning the front pins of the rack adapter plates with corresponding holes in the front of the rail, then adjust the rail to fit the rack and insert the pins from the rear rack adapter plates into the corresponding holes of the rail.
Page 112 Installing a Sun Disk Shelf Install four 8-32 screws into the four remaining front and rear holes of each rack rail (16 total). Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 113 Installing a Sun Disk Shelf Using a mechanical lift or two people, one at each side of the shelf or controller, carefully lift and rest the shelf on the bottom ledge of the left and right rails. The following graphic illustrates the chassis insertion. Carefully slide the shelf into the cabinet until the front flanges of the shelf touch the vertical face of the rack.
Page 114 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 115: Installing A Zs9-2 Controller
Installing a ZS9-2 Controller This section contains installation procedures for the ZS9-2 controller. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a ZS9-2 controller: “Installing the Slide Rails onto a ZS9-2” on page 115 ■...
Page 116: Installing The Slide Rails Into The Rack For A Zs9-2
Align the slide-rail assembly mounting pins with the front and rear rack post mounting holes. Then lock the assembly into place by pushing the assembly Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 117 Installing the Slide Rails into the Rack for a ZS9-2 toward the rear of the rack until the mounting pins engage the rack with an audible click. Note - The slide rails can be used with either 9.5-mm square or M6 round mounting hole racks. (Optional) If installing the assembly with cage nuts and mounting screws, insert the cage nuts into the front and rear rack posts in the desired positions.
Page 118: Installing A Zs9-2 Onto The Rack Slide Rails
If your rack includes an anti-tip foot, extend it from the bottom of the rack. Lower the rack stabilization feet if you have not already done so. Push the slide rails into the slide-rail assemblies in the rack as far as possible. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 119 Installing a ZS9-2 onto the Rack Slide Rails Raise the chassis so that the back ends of the mounting brackets are aligned with the slide rail (1) and insert the chassis into the slide rails, pushing the chassis slowly, until the mounting brackets meet the slide-rail stops (approximately 12 inches, or 30 cm).
Page 120: Installing A Zs9-2 Cable Management Arm
To prepare for installing the optional cable management arm (CMA), follow these guidelines: Before You Begin Route cables in the following priority until the CMA is full: ■ 1. Cluster cables 2. SAS active optical cables (AOCs) Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 121 Installing a ZS9-2 Cable Management Arm 3. SAS copper cables 4. Host optical cables (Ethernet, Fibre Channel) 5. Power cables All excess cabling that cannot be fitted through the CMA should be attached to the side of the rack and properly dressed (Velcro straps, and so on). Allow enough slack (service loop) for serviceability.
Page 122 Front slide bar Velcro straps (6) Connector B Connector C Connector D Slide-rail latching bracket (used with connector D) Back slide bar Controller flat cable covers Controller round cable covers Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 123 Installing a ZS9-2 Cable Management Arm Ensure that you install the round, not flat, cable covers for your controller on the CMA. If flat covers are installed, replace them with round cable covers. Ensure that the six Velcro straps are threaded into the CMA. Ensure that the two Velcro straps located on the front slide bar are threaded through Note - the opening in the top of the slide bar, as shown in the illustration in Step 1.
Page 124 Insert CMA connector B into the front slot on the right slide-rail until it locks into place with an audible click [frames 1 and 2]. The connector B tab (callout 1) goes into the slide-rail front slot (callout 2). Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 125 Installing a ZS9-2 Cable Management Arm Gently tug on the right side of the front slide bar to verify that connector B is properly seated. Callout Description Connector B tab Right slide-rail front slot To install CMA connector C into the right slide-rail: Installing a ZS9-2 Controller...
Page 126 Insert connector C into the right slide-rail until it locks into place with an audible click [frames 2 and 3]. Gently tug on the right side of the CMA back slide bar to verify that connector C is properly seated. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 127 Installing a ZS9-2 Cable Management Arm To prepare CMA connector D for installation, remove the tape that secures the slide-rail latching bracket to connector D, and ensure that the latching bracket is properly aligned with connector D [frames 1 and 2]. The CMA is shipped with the slide-rail latching bracket taped to connector D.
Page 128: Verifying Operation Of Zs9-2 Slide-Rails And Cma
Slowly pull the storage controller out of the rack until the slide-rails reach their stops. Inspect the attached cables for any binding or kinks. Verify that the CMA extends fully with the slide-rails. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 129 Verifying Operation of ZS9-2 Slide-Rails and CMA Push the storage controller back into the rack and verify that the CMA retracts without binding. Adjust the cable straps and the CMA, as required. Installing a ZS9-2 Controller...
Page 130 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 131: Installing A Zs7-2 Controller
Installing a ZS7-2 Controller This section contains installation procedures for the ZS7-2 controller. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a ZS7-2 controller: “Installing the Slide Rails onto a ZS7-2” on page 131 ■...
Page 132: Installing The Slide Rails Into The Rack For A Zs7-2
Align the slide-rail assembly mounting pins with the front and rear rack post mounting holes. Then lock the assembly into place by pushing the assembly Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 133 Installing the Slide Rails into the Rack for a ZS7-2 toward the rear of the rack until the mounting pins engage the rack with an audible click. Note - The slide rails can be used with either 9.5-mm square or M6 round mounting hole racks. (Optional) If installing the assembly with cage nuts and mounting screws, insert the cage nuts into the front and rear rack posts in the desired positions.
Page 134: Installing A Zs7-2 Onto The Rack Slide Rails
If your rack includes an anti-tip foot, extend it from the bottom of the rack. Lower the rack stabilization feet if you have not already done so. Push the slide rails into the slide-rail assemblies in the rack as far as possible. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 135 Installing a ZS7-2 onto the Rack Slide Rails Raise the chassis so that the back ends of the mounting brackets are aligned with the slide rail (1) and insert the chassis into the slide rails, pushing the chassis slowly, until the mounting brackets meet the slide-rail stops (approximately 12 inches, or 30 cm).
Page 136: Installing A Zs7-2 Cable Management Arm
To prepare for installing the optional cable management arm (CMA), follow these guidelines: Before You Begin Route cables in the following priority until the CMA is full: ■ 1. Cluster cables 2. SAS active optical cables (AOCs) Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 137 Installing a ZS7-2 Cable Management Arm 3. SAS copper cables 4. Host optical cables 5. Host copper cables (Ethernet, InfiniBand, Fibre Channel) 6. Power cables All excess cabling that cannot be fitted through the CMA should be attached to the side of the rack and properly dressed (Velcro straps, and so on).
Page 138 Front slide bar Velcro straps (6) Connector B Connector C Connector D Slide-rail latching bracket (used with connector D) Back slide bar Controller flat cable covers Controller round cable covers Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 139 Installing a ZS7-2 Cable Management Arm Ensure that you install the round, not flat, cable covers for your controller on the CMA. If flat covers are installed, replace them with round cable covers. Ensure that the six Velcro straps are threaded into the CMA. Ensure that the two Velcro straps located on the front slide bar are threaded through Note - the opening in the top of the slide bar, as shown in the illustration in Step 1.
Page 140 Insert CMA connector B into the front slot on the right slide-rail until it locks into place with an audible click [frames 1 and 2]. The connector B tab (callout 1) goes into the slide-rail front slot (callout 2). Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 141 Installing a ZS7-2 Cable Management Arm Gently tug on the right side of the front slide bar to verify that connector B is properly seated. Callout Description Connector B tab Right slide-rail front slot To install CMA connector C into the right slide-rail: Installing a ZS7-2 Controller...
Page 142 Insert connector C into the right slide-rail until it locks into place with an audible click [frames 2 and 3]. Gently tug on the right side of the CMA back slide bar to verify that connector C is properly seated. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 143 Installing a ZS7-2 Cable Management Arm To prepare CMA connector D for installation, remove the tape that secures the slide-rail latching bracket to connector D, and ensure that the latching bracket is properly aligned with connector D [frames 1 and 2]. The CMA is shipped with the slide-rail latching bracket taped to connector D.
Page 144: Verifying Operation Of Zs7-2 Slide-Rails And Cma
Slowly pull the storage controller out of the rack until the slide-rails reach their stops. Inspect the attached cables for any binding or kinks. Verify that the CMA extends fully with the slide-rails. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 145 Verifying Operation of ZS7-2 Slide-Rails and CMA Push the storage controller back into the rack and verify that the CMA retracts without binding. Adjust the cable straps and the CMA, as required. Installing a ZS7-2 Controller...
Page 146 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 147: Installing A Zs5-4 Controller
Installing a ZS5-4 Controller This section contains installation procedures for the ZS5-4 controller. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a ZS5-4 controller: “Installing the Slide Rails onto a ZS5-4” on page 147 ■...
Page 148: Installing The Slide Rails Into The Rack For A Zs5-4
Position a slide-rail assembly in your rack so that the slide-rail assembly front bracket is on the outside of the front rack post and the slide-rail assembly rear bracket is on the inside of the rear rack post. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 149 Installing the Slide Rails into the Rack for a ZS5-4 Align the slide-rail assembly mounting pins with the front and rear rack post mounting holes. Then lock the assembly into place by pushing the assembly toward the rear of the rack until the mounting pins engage the rack with an audible click.
Page 150: Installing A Zs5-4 Onto The Rack Slide Rails
Always load the heaviest equipment (disk shelves) at the bottom of the rack. If your rack includes an anti-tip foot, extend it from the bottom of the rack. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 151 Installing a ZS5-4 onto the Rack Slide Rails Lower the rack stabilization feet if you have not already done so. Push the slide rails into the slide-rail assemblies in the rack as far as possible. Raise the chassis so that the back ends of the mounting brackets are aligned with the slide rail and insert the chassis into the slide rails, pushing the chassis slowly, until the mounting brackets meet the slide-rail stops (approximately 12 inches, or 30 cm).
Page 152: Installing A Zs5-4 Cable Management Arm
■ located above and below them, you can divide the disk shelf SAS cables between the two CMAs so they properly route to the upper and lower disk shelves. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 153 Installing a ZS5-4 Cable Management Arm If later removing the CMA, be sure to support it as you remove the connectors. ■ Insert the CMA mounting bracket connector (1) into the right slide rail (2) until the connector locks into place with an audible click. Insert the right CMA slide-rail connector (1) into the right slide-rail assembly (2) until the connector locks into place with an audible click.
Page 154: Verifying Operation Of Zs5-4 Slide-Rails And Cma
Slowly pull the storage controller out of the rack until the slide-rails reach their stops. Inspect the attached cables for any binding or kinks. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 155 Verifying Operation of ZS5-4 Slide-Rails and CMA Verify that the CMA extends fully with the slide-rails. Push the storage controller back into the rack and verify that the CMA retracts without binding. Adjust the cable straps and the CMA, as required. Installing a ZS5-4 Controller...
Page 156 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 157: Installing A Zs5-2 Controller
Installing a ZS5-2 Controller This section contains installation procedures for the ZS5-2 controller. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a ZS5-2 controller: “Installing the Mounting Brackets and Slide Rail Assemblies for a ZS5-2” on page 157 ■...
Page 158 Installing the Mounting Brackets and Slide Rail Assemblies for a ZS5-2 Push the mounting bracket release button toward the front of the mounting bracket (2) while withdrawing the bracket from the assembly. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 159 Installing the Mounting Brackets and Slide Rail Assemblies for a ZS5-2 Attach a mounting bracket to each side of the controller. Installing a ZS5-2 Controller...
Page 160 If you are using a universal 19-inch cabinet, snap an M6 square cage nut into the top and bottom holes of the location where you will be installing the rail plate as shown. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 161 Installing the Mounting Brackets and Slide Rail Assemblies for a ZS5-2 Position a slide rail assembly in your rack so that the brackets at each end of the slide rail assembly are on the outside of the front and back rack posts. The following graphic illustrates the rail assembly brackets.
Page 162 Remove the spacer and confirm that the rails are attached tightly to the rack. Stabilize the rack, using all anti-tilt mechanisms, to prevent it from tipping during installation. See your rack documentation for detailed instructions. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 163: Installing A Zs5-2 Onto The Rack Slide Rails
Installing a ZS5-2 onto the Rack Slide Rails Installing a ZS5-2 onto the Rack Slide Rails Use the following procedure to install a ZS5-2 controller onto the rack slide rails. This procedure requires a minimum of two people because of the weight of the Caution - chassis.
Page 164: Installing A Zs5-2 Cable Management Arm
■ If the CMA has flat cable covers (for a 1U chassis), install the 2U round cable covers provided in the accessory kit. To replace the flat cable covers: Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 165 Installing a ZS5-2 Cable Management Arm Remove each flat cable cover by lifting up on the cable cover handle. Open it 180 degrees to the horizontal position. Apply upward pressure to the outside edge of each hinge connector until the hinge connector comes off the hinge.
Page 166 At the back of the rack, insert the CMA's connector A into the front slot on the left slide-rail until it locks into place with an audible click (frames 1 and 2). Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 167 Installing a ZS5-2 Cable Management Arm The connector A tab (1) goes into the slide-rail's front slot (2). Gently tug on the left side of the front slide bar to verify that connector A is properly seated. Support the CMA and do not allow it to hang under its own weight until it is secured at all four attachment points.
Page 168 Insert connector C into the right side-rail until it locks into place with an audible click (frames 2 and 3). Ensure that the end latch of the center bar mount engages with the rail notch during server pullout; see also step 14. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 169 Installing a ZS5-2 Cable Management Arm Gently tug on the right side of the CMA's rear slide bar to verify that connector C is properly seated. Installing a ZS5-2 Controller...
Page 170 While holding the slide-rail latching bracket in place, insert connector D and its associated slide-rail latching bracket into the left slide-rail until connector D locks into place with an audible click (frames 1 and 2). Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 171 Installing a ZS5-2 Cable Management Arm When inserting connector D into the slide-rail, the preferred and easier method is to install connector D and the latching bracket as one assembly into the slide-rail. Gently tug on the left side of the CMA's rear slide bar to verify that connector D is properly seated.
Page 172 Open the CMA cable covers, route controller cables through the CMA's cable troughs, close the cable covers, and secure the cables with the six Velcro straps. Route the cables through the cable troughs in this order: Route the cables Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 173 Installing a ZS5-2 Cable Management Arm through the front-most cable trough, then through the small cable trough, then through the rear-most cable trough. When securing the cables with the Velcro straps located on the front slide bar, ensure that the Velcro straps do not wrap around the bottom of the slide bar. Otherwise, expansion and contraction of the slide bar might be hindered when the server is extended from the rack and returned to the rack.
Page 174: Verifying Operation Of Zs5-2 Slide-Rails And Cma
Verify that the CMA extends fully with the slide-rails. Push the storage controller back into the rack and verify that the CMA retracts without binding. Adjust the cable straps and the CMA, as required. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 175: Installing A Zs4-4 Or Zs3-4 Controller
Installing a ZS4-4 or ZS3-4 Controller This section contains installation procedures for the ZS4-4 or ZS3-4 controller. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a ZS4-4 or ZS3-4 controller: “Installing the Slide Rails onto a ZS4-4 or ZS3-4” on page 175 ■...
Page 176: Installing The Slide Rails Into The Rack For A Zs4-4 Or Zs3-4
Refer to the Rail Rackmount Kit Overview and Information card for instructions on inserting these cage nuts. This card is included with the rack kit. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 177 Installing the Slide Rails into the Rack for a ZS4-4 or ZS3-4 Position a slide-rail assembly in your rack so that the slide-rail assembly front bracket is on the outside of the front rack post and the slide-rail assembly rear bracket is on the inside of the rear rack post.
Page 178: Installing A Zs4-4 Or Zs3-4 Onto The Rack Slide Rails
Attempting this procedure alone could result in equipment damage or personal injury. Always load the heaviest equipment (disk shelves) at the bottom of the rack. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 179 Installing a ZS4-4 or ZS3-4 onto the Rack Slide Rails If your rack includes an anti-tip foot, extend it from the bottom of the rack. Lower the rack stabilization feet if you have not already done so. Push the slide rails into the slide-rail assemblies in the rack as far as possible. Raise the chassis so that the back ends of the mounting brackets are aligned with the slide rail and insert the chassis into the slide rails, pushing the chassis slowly, until the mounting brackets meet the slide-rail stops (approximately 12...
Page 180 Continue pushing until the slide-rail locks (on the front of the mounting brackets) engage the slide- rail assemblies with an audible click. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 181: Installing A Zs4-4 Or Zs3-4 Cable Management Arm
Installing a ZS4-4 or ZS3-4 Cable Management Arm Verify that the controller is securely mounted in the rack and that the slide-rail locks Caution - are engaged with the mounting brackets before continuing, or equipment damage and possibly personal injury could occur. Installing a ZS4-4 or ZS3-4 Cable Management Arm Use the following procedure to install the cable management arm (CMA) for a ZS4-4 or ZS3-4 controller.
Page 182 Cable hooks and loop straps are preinstalled on the CMA. Perform this step if you need Note - to reinstall cable hooks and straps. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 183 Installing a ZS4-4 or ZS3-4 Cable Management Arm For best results, place three cable straps (1), evenly spaced, on the rear-facing side of the CMA arm (2), and three cable straps on the side of the CMA nearest the controller. Installing a ZS4-4 or ZS3-4 Controller...
Page 184 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 185: Installing A Zs3-2 Controller
Installing a ZS3-2 Controller This section contains installation procedures for the ZS3-2 controller. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a ZS3-2 controller: “Installing the Mounting Brackets and Slide Rail Assemblies for a ZS3-2” on page 185 ■...
Page 186 Installing the Mounting Brackets and Slide Rail Assemblies for a ZS3-2 Push the mounting bracket release button toward the front of the mounting bracket (2) while withdrawing the bracket from the assembly. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 187 Installing the Mounting Brackets and Slide Rail Assemblies for a ZS3-2 Attach a mounting bracket to each side of the controller. Installing a ZS3-2 Controller...
Page 188 If you are using a universal 19-inch cabinet, snap an M6 square cage nut into the top and bottom holes of the location where you will be installing the rail plate as shown. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 189 Installing the Mounting Brackets and Slide Rail Assemblies for a ZS3-2 Position a slide rail assembly in your rack so that the brackets at each end of the slide rail assembly are on the outside of the front and back rack posts. The following graphic illustrates the rail assembly brackets.
Page 190 Remove the spacer and confirm that the rails are attached tightly to the rack. Stabilize the rack, using all anti-tilt mechanisms, to prevent it from tipping during installation. See your rack documentation for detailed instructions. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 191: Installing A Zs3-2 Onto The Rack Slide Rails
Installing a ZS3-2 onto the Rack Slide Rails Installing a ZS3-2 onto the Rack Slide Rails Use the following procedure to install a ZS3-2 controller onto the rack slide rails. This procedure requires a minimum of two people because of the weight of the Caution - chassis.
Page 192: Installing A Zs3-2 Cable Management Arm
If the CMA has flat cable covers (for a 1U chassis), install the 2U round cable covers provided in the accessory kit. To replace the flat cable covers: Remove each flat cable cover by lifting up on the cable cover handle. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 193 Installing a ZS3-2 Cable Management Arm Open it 180 degrees to the horizontal position. Apply upward pressure to the outside edge of each hinge connector until the hinge connector comes off the hinge. Position each round cable cover horizontally over the hinges, and align the hinge connectors with the hinges.
Page 194 Insert the CMA's connector B into the front slot on the right slide-rail until it locks into place with an audible click (frames 1 and 2). Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 195 Installing a ZS3-2 Cable Management Arm The connector B tab (1) goes into the slide-rail front slot (2). Gently tug on the right side of the front slide bar to verify that connector B is properly seated. To install the CMA's connector C into the right slide-rail, perform the following steps: Align connector C with the slide-rail so that the locking spring (1) is positioned inside (server side) of the right slide-rail (frame 1).
Page 196 Installing a ZS3-2 Cable Management Arm Gently tug on the right side of the CMA's rear slide bar to verify that connector C is properly seated. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 197 Installing a ZS3-2 Cable Management Arm To prepare the CMA's connector D for installation, remove the tape that secures the slide-rail latching bracket to connector D and ensure that the latching bracket is properly aligned with connector D (frames 1 and 2). While holding the slide-rail latching bracket in place, insert connector D and its associated slide-rail latching bracket into the left slide-rail until connector D locks into place with an audible click (frames 1 and 2).
Page 198 Verify that the slide-rails and the CMA are operating properly before routing cables through the CMA: Ensure all rack anti-tilt devices are extended to prevent the rack from tipping. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 199 Installing a ZS3-2 Cable Management Arm Extend the controller from the front of the rack until the CMA is fully extended. Return the storage controller to the rack. As you push the storage controller into the rack, verify that the CMA retracts without binding. Open the CMA cable covers, route controller cables through the CMA's cable troughs, close the cable covers, and secure the cables with the six Velcro straps.
Page 200 CMA components; otherwise, expansion and contraction of the CMA slide bars might be hindered when the server is extended from the rack and returned to the rack. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 201: Verifying Operation Of Zs3-2 Slide-Rails And Cma
Verifying Operation of ZS3-2 Slide-Rails and CMA Verifying Operation of ZS3-2 Slide-Rails and CMA Use the following procedure to verify the operation of the optional CMA and slide rails on a ZS3-2 controller. Ensure all rack anti-tilt devices are extended to prevent the rack from tipping forward when the Before You Begin storage controller is extended from the rack.
Page 202 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 203: Installing A 7X20 Controller
Installing a 7x20 Controller This section contains installation procedures for the 7420, 7320, and 7120 controllers. Before beginning installation, see “Installation Prerequisites and Hardware Overviews” on page Use the following procedures to install a 7x20 controller: “Removing the 7x20 Mounting Brackets from inside the Slide Rails” on page 203 ■...
Page 204 Removing the 7x20 Mounting Brackets from inside the Slide Rails Example 2 Disassembling a 7420 Rail Kit The following graphic illustrates the procedure for disassembling the 7420 rail kit. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 205: Installing The Mounting Brackets On A 7X20
Installing the Mounting Brackets on a 7x20 Installing the Mounting Brackets on a 7x20 Use the following procedure to install the mounting brackets on a 7420, 7320, or 7120 controller. If the mounting brackets are shipped inside the slide rails, you must remove them before Note - beginning this procedure;...
Page 206 Installing the Mounting Brackets on a 7x20 The following graphic illustrates how to attach the 7120/7320 mounting brackets. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 207: Installing A 7X20 Onto The Rack Slide Rails
Installing a 7x20 onto the Rack Slide Rails The following graphic illustrates how to attach the 7x20 mounting brackets. With the heads of the four chassis locating pins protruding through the four keyhole openings in the mounting bracket, pull the mounting-bracket toward the front of the chassis until the mounting-bracket clip locks into place with an audible click.
Page 208 Position a slide rail assembly in your rack so that the brackets at each end of the slide rail assembly are on the outside of the front and back rack posts. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 209 Installing a 7x20 onto the Rack Slide Rails The following graphic illustrates the rail assembly brackets. Attach each slide rail assembly to the rack posts, but do not tighten the screws completely. Installing a 7x20 Controller...
Page 210 (~12 in or 30 cm). You will hear an audible click. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 211 Installing a 7x20 onto the Rack Slide Rails Installing a 7120/7320 onto the Rack Slide Rails Example 3 The following graphic illustrates the 7120/7320 chassis insertion and slide rail locks usage. Installing a 7420 onto the Rack Slide Rails Example 4 The following graphic illustrates 7420 chassis insertion.
Page 212: Installing A 7X20 Cable Management Arm
Do not route short SAS daisy chain cables through the CMA. Do not route an excess of ■ cables such that the CMA clamps bow or appear structurally unfit to support the weight. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 213 Installing a 7x20 Cable Management Arm If using two clustered controllers mounted in the middle of the rack with disk shelves ■ located above and below them, you can divide the disk shelf SAS cables between the two CMAs so they properly route to the upper and lower disk shelves. If later removing the CMA, be sure to support it as you remove the connectors.
Page 214 Installing a 7x20 Cable Management Arm Insert the CMA mounting bracket connector into the right slide rail until the connector locks into place. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 215 Installing a 7x20 Cable Management Arm Insert the right CMA slide rail connector (1) into the right slide rail assembly (2) until the connector locks into place. Installing a 7x20 Controller...
Page 216 Installing a 7x20 Cable Management Arm Insert the left CMA slide rail connector (1) into the rail extension on the left slide rail assembly (2) until the connector locks into place. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 217 Installing a 7x20 Cable Management Arm After you install and route the cables through the assembly, attach the hook and loop straps (1) to secure the cables. Then attach the right and left outer latches to support the assembly. Installing a 7x20 Controller...
Page 218 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 219: Cabling The Appliance
Guide. Connecting System Cables Use the following procedure to make a physical serial or network connection to Oracle ILOM. It is strongly recommended that you use a serial SP connection for system configuration and initial configuration because you can monitor progress, especially during system reboots.
Page 220: Connecting Cluster Cables
The following sections describe how to connect cluster cables for different controllers. Connecting Cluster Cables for ZS9-2 Controllers ZS9-2 controllers employ Ethernet-based clustering using two Ethernet ports in the Oracle Quad Port 10GBASE-T Ethernet Adapter. See ZS9-2 Controller Cluster I/O Ports for details about the ZS9-2 controller cluster interface card.
Page 221: Connecting Cluster Cables For Zs7-2, Zs5-X, Zs4-4, Zs3-X, And 7X20 Controllers
Connecting Cluster Cables Two Category 6A Ethernet cables with RJ-45 connectors are provided: one green and one red. Each cable is 2.5 meters in length. Connect either the green cable or the red cable from Ethernet port 0 of one controller to ■...
Page 222 Connect the second cable from serial port 1 of one controller to serial port 0 of the other ■ controller. Connect the third cable between the Ethernet ports of each controller. ■ The following figure shows cluster cabling between two ZS5-4 controllers. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 223 Connecting Cluster Cables ZS5-4 Controller Cluster Cabling FIGURE 50 The following figure shows cluster cabling between two ZS5-2 controllers. ZS5-2 Controller Cluster Cabling FIGURE 51 ZS4-4 Cluster Cabling Three Category 5 Ethernet cables are provided. Each cable is 1 meter in length. Connect the cables in the same way as described for ZS5-x controllers.
Page 224 ZS5-x controllers. For details about the cluster ports, ZS3-2 Controller Cluster I/O Ports. The following figure shows cluster cabling between two ZS3-2 controllers. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 225: Controller Cluster I/O Ports
For the location of these cluster interface cards, see the hardware overview for the appropriate controller. ZS9-2 controllers employ Ethernet-based clustering using two Ethernet ports in the Oracle Quad Port 10GBASE-T Ethernet Adapter. All other controller cluster interface cards employ serial-based clustering using two serial cluster links, and provide Ethernet connectivity via one link.
Page 226 5 Port 1 (Cluster Link) 6 Port 0 (Cluster Link) The following diagram illustrates the cluster serial and Ethernet ports for ZS7-2, ZS5-4, ZS5-2, ZS4-4, ZS3-4, and 7x20 controllers. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 227 Controller Cluster I/O Ports ZS7-2, ZS5-4, ZS5-2, ZS4-4, ZS3-4, and 7x20 Controller Cluster I/O Ports FIGURE 55 Figure Legend 1 Serial 1 2 Ethernet 3 Serial 0 4 Serial Link Status LED 5 Ethernet Link Status LED 6 Ethernet Activity LED The following diagram illustrates the cluster serial and Ethernet ports for ZS3-2 controllers.
Page 228: Connecting Disk Shelf Cables
Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 229 “Getting Started with Cabling” in Oracle ZFS Storage Appliance Cabling Guide. “Cabling DE3-24 Disk Shelves to 4X4 Port SAS-3 HBAs” in Oracle ZFS Storage ■ Appliance Cabling Guide “Cabling DE2-24 Disk Shelves to 4X4 Port SAS-2 HBAs” in Oracle ZFS Storage ■...
Page 230 Shelf 7 (RU 31-34) Shelf 4 (RU 13-16) Shelf 6 (RU 27-30) Shelf 3 (RU 9-12) Shelf 5 (RU 23-26) Shelf 2 (RU 5-8) Controller 1 (RU 20-22) Shelf 1 (RU 1-4) Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 231: Powering On The Appliance
Powering On the Appliance This section contains power-on procedures for Oracle ZFS Storage Appliance disk shelves and storage controllers. Do not power on disk shelves and controllers until all other cabling is complete, as Caution - described in “Cabling the Appliance” on page 219.
Page 232 235. If the module status indicator is not a steady green after module reinsertion and powering on, contact Oracle Customer Service. Related Topics “Powering Off a Disk Shelf” on page 235 ■ Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 233: Powering On A Sun Disk Shelf
“Powering Off a Controller” on page 234 ■ Powering On a Controller Use the following procedure to power on an Oracle ZFS Storage Appliance controller. Plug power cables into power supply 0 and power supply 1 on the storage controller(s).
Page 234: Powering Off A Controller
Power/OK status indicator on the front panel flashes, indicating that the storage controller is in standby power mode. To completely remove power, disconnect the AC power cords from the rear panel of the storage controller. Related Topics Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 235: Powering Off A Disk Shelf
Powering Off a Disk Shelf “Powering Off a Disk Shelf” on page 235 ■ “Powering On a Controller” on page 233 ■ Powering Off a Disk Shelf If a disk shelf is a part of a storage pool, powering off or removing all SAS chains from a disk shelf will trigger a kernel panic on the controller(s) to prevent data loss, unless the shelf is part of an NSPF (no single point of failure) data pool.
Page 236 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 237: Configuring The Appliance For The First Time
This section contains first-time configuration procedures for Oracle ZFS Storage Appliance. Follow these steps to complete first-time configuration: 1. Ensure you have completed cabling, including the serial or network cabling for Oracle ILOM connectivity, as described in “Cabling the Appliance” on page 219.
Page 238: Configuring The System
After the cluster is initialized, you can administer the system from either storage controller. However, do not attempt initial configuration on both controllers independently. Open a terminal or terminal emulator window and log in to Oracle ILOM in one of the following ways: For a serial connection (recommended), use as the user name.
Page 239 MAC address (see the label on the storage controller). For example: ssh root@192.168.128.256 When prompted, enter the password changeme This is the default password that provides initial access to Oracle ILOM. You can set a Note - different password for the appliance in step 5. At the command prompt, enter...
Page 240 Copyright (c) 2008, 2021, Oracle and/or its affiliates. Your new appliance is now ready for configuration. To configure your appliance, use a web browser to visit the following link: Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 241: Performing Initial Configuration (Bui)
BUI for initial configuration. For clustered controllers, configure only the primary controller. Do not attempt initial configuration on both controllers independently. For more information about clustering, see “Appliance Cluster Configuration” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Gather the following information for the interfaces and services you will set up, and ■...
Page 242 The login screen appears. If the login screen does not appear and an error message is displayed instead, add an Note - exception and download the certificate. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 243 Performing Initial Configuration (BUI) Log in to the appliance: Username - Enter root. Password - Password you assigned during system configuration. Click LOGIN or press Enter. To begin initial configuration, click START. If configuring clustered controllers, go to step 5. ■...
Page 244 Note - step 6. To configure clustered controllers later, see “Upgrading a Standalone Appliance to a Clustered Configuration (BUI)” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Ensure that there are solid lines in the active cluster links diagram and click COMMIT.
Page 245 Performing Initial Configuration (BUI) All Other Controllers: Set the appliance name and password for the peer controller: Appliance Name - Enter the peer controller name (must be different from primary ■ controller name). Root Password - Enter the same password that you set for the appliance during system ■...
Page 246 Datalinks. In the Network Datalink dialog box, set the following minimum datalink properties. VNIC - Select this check box. ■ Name - Enter a name for the datalink. ■ Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 247 Performing Initial Configuration (BUI) For detailed information, see the following tasks: “Creating a VNIC Without a VLAN ID for Clustered Controllers (BUI)” in Oracle ■ ZFS Storage Appliance Administration Guide, Release OS8.8.x “Creating VNICs with the Same VLAN ID for Clustered Controllers (BUI)” in Oracle ■...
Page 248 For clustered controllers, repeat steps a-f for the second controller, and choose a unique controller name. Click the trash icon next to the default interface, named Untitled Interface, to destroy it and click APPLY. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 249 Note - appliance via the BUI and CLI. Without a route, the only means of communication with the appliance is through an Oracle ILOM connection to the SP. To configure additional routing, go to step 7. Otherwise, click COMMIT and skip to step 8.
Page 250 Interface - Select the interface for which you want to configure routing. ■ Click ADD. The new route appears in the routing table. Click COMMIT. Configure the Domain Name Service (DNS) and click COMMIT. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 251 Performing Initial Configuration (BUI) For detailed information, see “DNS Configuration” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Configure the Network Time Protocol (NTP) to synchronize the appliance clock by performing one of the following options and then click COMMIT: To automatically discover the NTP server and set the appliance time to match your network ■...
Page 252 SMB users are authenticated. In domain mode, SMB clients are authenticated through the Active Directory domain controller, and you must ensure that the times on the appliance and the domain controller match within five minutes. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 253 Otherwise, click CONFIGURE to adjust the settings for a service. Configure storage pools and click COMMIT. For detailed information, see “Configuring Storage” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Perform one of the following steps: To register your appliance for remote support, complete the fields and click ■...
Page 254 Performing Initial Configuration (BUI) If you do not have an Oracle support account, click LATER and see “Phone Home Configuration” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. To skip remote support configuration, click LATER. ■ Perform one of the following steps: If you clicked REGISTER in the previous step, read the privacy statement ■...
Page 255 OS8.8.x. If you did not configure the management interface yet, see the tasks in “Configuring ■ Management Interfaces” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Related Topics For an overview of network interface configuration, see “Network Configuration” in Oracle ■...
Page 256: Performing Initial Configuration (Cli)
You can create a management interface now, or at another time using a task in Note - “Configuring Management Interfaces” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. aksh: starting configuration with "net" ... Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 257 Performing Initial Configuration (CLI) Configure Networking. Configure the appliance network interfaces. The first network interface has been configured for you, using the settings you provided at the serial console. Subcommands that are valid in this context: datalinks => Manage datalinks devices =>...
Page 258 Properties: state = up curaddrs = 192.0.2.11/24 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 259 (uncommitted)> commit hostname:maintenance system setup net interfaces igb0> cd ../.. Configure the Domain Name Service (DNS). For detailed information, see “DNS Configuration” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Configure DNS. Configure the Domain Name Service.
Page 260 => Show information pertinent to the current context commit => Commit current state, including any changes abort => Abort this task (potentially resulting in a misconfigured system) done => Finish operating on "ntp" Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 261 "ntp", advancing configuration to "directory" ... Configure name services. For detailed information, see “Configuring Services” in Oracle ZFS Storage Appliance Administration Guide, Release OS8.8.x. Active Directory has two modes: domain and workgroup mode, which dictate how Note - SMB users are authenticated.
Page 262 => Commit current state, including any changes done => Finish operating on "storage" config <pool> => Configure the storage pool unconfig => Unconfigure the storage pool => Add additional storage to the storage pool Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 263 "storage", advancing configuration to "support" ... Configure remote support. You can configure remote support now, or at another time. If you do not have an Oracle Note - support account, enter done without configuring remote support and complete it later. For more information about configuring remote support later or obtaining an Oracle support account, see “Phone Home Configuration”...
Page 264 “Configuring the Appliance” in Oracle ZFS Storage ■ Appliance Administration Guide, Release OS8.8.x. To change the root password, see “Changing a User Password (CLI)” in Oracle ZFS ■ Storage Appliance Administration Guide, Release OS8.8.x. Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...
Page 265: Troubleshooting Hardware Faults
In rare cases, faults associated with uncorrectable CPU errors are not diagnosable or displayed in the controller. These faults will be preserved by and observable in the Oracle ILOM, located in the service processor. Connect to Oracle ILOM on the server platform to diagnose hardware faults that do not appear in the BUI.
Page 266 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021...

Oracle ZFS Installation Manual

Quick Links

Related Manuals for Oracle ZFS

Summary of Contents for Oracle ZFS

Table of Contents
