management workstations. The customer uses the GUI for long-term
management and monitoring of the Oracle FS System.
Prerequisites:
•
•
•
•
•
1
From the customer's management workstation, open a web browser and
enter the IP address or the hostname of the customer management
network.
2
Click Management Software.
3
Select the link for the version of the GUI installer that you want to
download, and save the file.
4
Run the installer to install the software.
Download Oracle FS Command Line Interface
You can use Oracle FS Command Line Interface (FSCLI) to configure and manage
the Oracle FS System. To install FSCLI, download the software from the Pilot and
install the software on the customer's management workstations.
Prerequisite:
The system is powered on.
1
From the customer's management workstation, open a web browser and
enter the IP address or the hostname of the customer management
network.
2
Click Management Software.
3
Select the link for the version of the CLI installer that you want to
download and save the file to the workstation.
4
Run the installer to install the software.
Configure and Connect to the Customer Management Network
Management workstations must be on a network that can access the
management IP addresses of the Pilot on port 80 or port 8080.
Workstations using the Oracle FS System Manager (GUI) or the Oracle FS
Command Line Interface (FSCLI) to manage or monitor the system must be
on a network configured to permit that workstation to reach the Pilot
management IP Ethernet interfaces on port 26012.
The system is powered on.
The IP addresses are set on the Pilots.
For JAVA Archive (JAR) installers, Java 1.7 or higher must be installed on the
workstations.
Note: The Windows MSI installers do not require Java to be installed on the
workstation.
162
