Oracle FS Systems: Cabling Overview
Figure 63: Controller ports for external cabling
Legend
1 SAN HBA ports connect the system to the customer data network (FC or iSCSI)
Controller Ports for Internal Cabling
The following figure shows the internal Ethernet ports and the SAS ports.
Figure 64: Controller ports for internal cabling
98
