Table 25: HBA options with SFPs
SFP option
16Gbs FC Optic SR
10Gbs iSCSI Optic SR
The following table summarizes the length limits for the optical cables that
connect to the Controller SAN ports:
Table 26: Cable length limits for FC configurations
Speed
8 Gb/s
10 Gb/s
(iSCSI)
16 Gb/s
Related Links
Handling and Care of Fiber Optic Cables
Types of Internal Cables
Types of Internal Cables
The types of internal cables for the Oracle FS System are summarized in the
sections below.
Note: If you require additional internal cables, you can order them from Oracle.
To find the cable part numbers for ordering purposes, open
Handbook
the Oracle FS1 Flash Storage System components list. Part numbers are listed in
the components list.
Private Management Network Cables
The following table lists the types of internal cables and the cable lengths that are
used for the Private Management Network.
SFP manufacturing part
number
7023325
7023315
OM1
OM2
68.89 feet (21
164.042 feet
meters)
(50 meters)
108.268 feet
272.31 feet
(33 meters)
(83 meters)
49.21 feet (15
114 .89 feet
meters)
(35 meters)
(https://support.oracle.com/handbook_partner/index.html) and go to
Oracle FS System Cables
Description
Used for fibre channel
networks (includes one pair
of SFPs)
Used for iSCSI (includes one
pair of SFPs)
OM3
OM4
492.126 feet (150
623.36 feet (190
meters)
meters)
1804.46 feet (550
984.252 feet (300
meters)
meters)
328.084 feet (100
410.105 feet (125
meters)
meters)
Oracle System
103
