Pilot Drive LED Indicators

There are three LEDs on each Pilot drive. There is only one drive in each Pilot.

Table 49: Pilot drive LED status and description

LED
OK to Remove
Service
Required
OK/Activity

Pilot Fan LED Indicators

Each Pilot fan module has one bicolored LED. These LEDs are on the Pilot side
wall next to the fan modules and are visible when the top cover fan door is open.

Table 50: Pilot fan LED status and description

LED
Fan Status
LED
Icon
LED color
Blue
Amber
Green
Icon
LED color
NONE
Bicolored:
Amber/
Green
Oracle FS System LED Status
Status
The storage drive can be
removed safely during a hot-
swap operation.
OFF – Normal
operation.
STEADY ON – The
system has detected a
fault with the storage
drive.
OFF – Power is off or the
system does not
recognize the installed
drive.
STEADY ON – The
drive is engaged and is
receiving power.
STEADY BLINK – There
is disk activity. Indicator
blinks on and off to
indicate activity
Status
Amber – There is a fan fault.
Green – Fan is properly installed
and operating correctly. No fan
errors detected.
214
