Table 4: Controller dimensions and weight (continued)
Attribute Value
Depth 20.25 in (51.435 cm)
Weight 41 lb (18.59 kg)

Table 5: DE2-24P Drive Enclosure dimensions and weight

Attribute Value
Height 3.46 in (8.79 cm); 2U
Weight (with 55 lb (24.9 kg)
drives)
Note: The final weight of the Drive Enclosure depends on the drive
type and the number of drives in each Drive Enclosure.
Width Width across mounting flange: 19 in (48.26 cm)
Width across body of enclosure: 17.44 in (44.29 cm)
Depth 24.8 in (62.99 cm)

Table 6: DE2-24C Drive Enclosure dimensions and weight

Attribute Value
Height 6.92 in (17.57 cm); 4U
Weight (with 110 lb (49.9 kg)
drives)
Width Width across mounting flange: 19.00 in (48.26 cm)
Width across body of enclosure: 17.44 in (44.29 cm)
Depth 24.80 in (62.99 cm)
Power Characteristics

Table 7: Pilot power characteristics

Power Value
characteristic
Frequency 50–60Hz
AC voltage 100–240V
Oracle FS Systems: Installation Overview
22
