Pilot Power Supply LED Indicators

There are two LEDs on each power supply. These LEDs are visible from the back
of the Pilot.

Table 54: Pilot Drive LED status and description

LED
AC OK/DC
OK
Service
Required
Icon LED color
Green
Amber
Oracle FS System LED Status
Status
OFF – No AC power is present.
•
SLOW BLINK – Normal
•
operation. Input power is within
specification. DC output voltage
is not enabled.
STEADY ON – Normal
•
operation. Input AC power and
DC output voltage are within
specification.
OFF – Normal operation; no
•
service required.
STEADY ON – The power
•
supply (PS) has detected a PS
fan failure, PS over-temperature,
PS over current, or PS over or
under voltage.
