Table 40: Controller LED status and description (back panel)

No. LED
1
Power supply
status LEDs:
2
Chassis Status
LEDs
LED color Status
(Top)
•
Output
Power OK
LED:
Green
(Middle)
•
Service
Action
Required
LED:
Amber
(Bottom)
•
AC or DC
Input
Power OK
LED:
Green
(Left)
•
Locator
LED and
button:
White
(Center)
•
Service
Action
Required
LED:
Amber
(Right)
•
Main
Power OK
LED:
Green
Oracle FS System LED Status
Output Power OK LED:
•
Indicates that output power
is without fault.
Service Action Required LED:
•
Indicates that service for the
power supply is required.
AC or DC Input Power OK
•
LED: Indicates that input
power is without fault.
Locator LED and button: The
•
Locator LED can be turned
on to identify a particular
system.
Service Action Required LED:
•
Indicates that service is
required. Under some fault
conditions, individual
component fault LEDs are
turned on in addition to the
Service Required LED.
Main Power OK LED:
•
Indicates these conditions:
Off – System is not
•
running in its normal
state. System power
might be off. The SP
might be running.
Steady on – System is
•
powered on and is
running in its normal
operating state. No
service actions are
required.
