to the Oracle FS System to indicate that it is operating in battery mode or in
normal mode and that the Oracle FS System should be configured to receive the
traps. For more information about managing APC products that can be
monitored and configured with SNMP, see the
Guide (http://www.apcmedia.com/salestools/JGAY-83UPH9/
JGAY-83UPH9_R0_EN.pdf). In short, a UPS system must be based on the
maximum wattage requirements of the sum total of all the Oracle FS System
components.
Related Links
Planning for a System Installation
Unpacking Systems
Check and Receive Components
System Power Requirements
PDU Hardware Specifications

Component Chassis Hardware Specifications

Component Chassis Hardware Specifications
The following tables provide information on the hardware specifications and the
power characteristics of the Pilot, Controller, and Drive Enclosures.
Dimensions and Weight

Table 3: Pilot dimensions and weight

Attribute
Height
Width
Depth (not
including power
supply handles)
Weight

Table 4: Controller dimensions and weight

Attribute
Height
Width
Value
1.68 in (4.26 cm)
Server chassis (not including ears): 17.19 in (43.65 cm)
Server chassis (with bezel): 18.90 in (48.24 cm)
29.00 in (73.66 cm)
40 lb (18.1437 kg): Weight of one Pilot.
Value
3.45 in (8.76 cm)
17.52 in (44.55 cm)
Oracle FS Systems: Installation Overview
Schneider Electric MIB Reference
21
