Wiring the EZStruder's Stepper Motor

After you've neatened up the stepper motor wires (ahem), tie the wires to the side of the
EZStruder mount using a wire tie and route the wires up through the center hole in the top plate.
Fig. 12-14:Routing the extruder wires.
At this point you have a decision to make on whether or not you want to install a latching
polarized connector to the stepper motor wires in the tower or not. If you do want to go that route,
please jump ahead to Appendix A: Quick Disconnects in your Rostock MAX v2.
