Rostock MAX v2 Assembly Guide
(___) 18 each, #6 Stainless Steel Flat washers. Used on the 608 bearings
that go in the top & bottom t-slot rails.
(___) 6 each, #4 Stainless Steel Flat washers. Used with the belt clamp
screws.
(___) 21 each, 608ZZ Ball Bearings. Used in the Cheapskates and belt
idlers.
(___) 1 each, #10-32, 5/8" Socket Head Cap Screw. Used as a tap for the
#10-32 Nylon thumb screws.
16
