Rostock MAX v2 Assembly Guide
Installing the Acrylic Cover Panels
The Rostock MAX v2 uses laser cut acrylic panels to cover the open spaces on the machine
base and on the top assembly. The bottom uses two different sized panels. The one that covers the
back of the Z axis is marked with a laser engraved "B" in the bottom corner.
Fig. 19-11:Rear acrylic cover.
202
