Rostock MAX v2 Assembly Guide
Slide two u-joints on to the u-joint axle as shown below. If your kit shipped with the injection molded
u-joints, make sure you slide the u-joint on to the axle with the ejector pin marks facing out. This will
prevent any plastic scale from scraping against the u-joint carriage.
Fig. 8-12:U-Joints installed.
