SeeMeCNC Rostock MAX v2 Assembly Manual page 14

Rostock MAX v2 Assembly Guide
(___) 6 each, #6-32, 5/8" Socket Head Cap Screws. Used for mounting
the U-Joint plates to the Cheapskate plates.
(___) 12 each, #6-32, 1-3/4" Phillips Pan Head Stainless Steel screws.
Used for 608 idlers in the motor mounts as well as the hot end standoffs.
(___) 63 each, #6-32 Stainless Steel Nylon Lock Nut – covers all #6-32
screws.
(___) 14 each, #6-32, 2" Phillips Pan Head Stainless Steel screws. Used
for Cheapskate plates and EZStruder mount.
(___) 15 each, #6-32, 1/2" 18-8 Stainless Steel Flathead screw. Used
inside of base and top side plates, to retain acrylic panels and the three
end-stop triggering screws installed in the Cheapskate U-Joint mounts.
(___) 25 each, #¼-20, 1/2" Stainless Steel Button Head Cap Screws.
Used for T-Slot mounting.
(___) 25 each, #¼-20 nut plates. Used for T-Slot mounting.
14
