www.ti.com
The third data byte consists of bits 7–0 of the hardware breakpoint. Thus, the second and third data bytes
set the CPU CODE address at which to stop execution.
3.4
Flash Programming
Programming of the on-chip flash is performed via the debug interface. The external host must initially
send instructions using the DEBUG_INSTR debug command to perform the flash programming with the
flash controller.
3.4.1 Lock Bits
For software and/or access protection, a set of lock bits can be written to the upper available flash
page—the lock-bit page. The lock-bit structure consists of 128 bits where the first (FLASH_PAGES-1)
each corresponds to the first flash pages available in the device. The last bit (at the highest address) is
the debug lock bit (see
when the upper flash bank is mapped in, and occupies 16 bytes. The rest of the lock-bit page can be used
to store code or constants, but cannot be changed without entering debug mode.
The PAGELOCK[FLASH_PAGES-2:0] lock-protect bits are used to enable erase and write protection for
individual flash memory pages (2 KB; 1 KB on CC2533). There is one bit for each available page.
When the debug-lock bit, DBGLOCK, is set to 0 (see
CHIP_ERASE, READ_STATUS, and GET_CHIP_ID are disabled. The status of the debug-lock bit can be
read using the READ_STATUS command (see
Note that after the debug-lock bit has changed due to a write to the lock-bit page or a CHIP_ERASE
command, the device must be reset to lock or unlock the debug interface.
Issuing a CHIP_ERASE command is the only way to clear the debug-lock bit, thereby unlocking the debug
interface.
Table 3-5
defines the 16-byte structure containing the flash lock-protection bits. Bit 0 of the first byte
contains the lock bit for page 0, bit 1 of the first byte contains the lock bit for page 1, and so on. Bit 7 of
the last byte in the flash is the DBGLOCK bit (bit 127 in the structure).
Bit
127
126:FLASH_PAGES-1
FLASH_PAGES-2:0
NOTE: It is recommended to lock all pages that are not to be in-system programmed. This is to
prevent erroneous code from unintentionally altering code or constants. This can only be
changed while in debug mode.
3.5
Debug Interface and Power Modes
Power modes PM2 and PM3 may be handled in two different ways when the chip is in debug mode. The
default behavior is never to turn off the digital voltage regulator. This emulates power modes while
maintaining debug mode operation. The clock sources are turned off as in ordinary power modes. The
other option is to turn off the 1.8-V internal digital power. This leads to a complete shutdown of the digital
part, which disables debug mode. When the chip is in debug mode, the two options are controlled by
configuration bit 5 (SOFT_POWER_MODE).
SWRU191F – April 2009 – Revised April 2014
Submit Documentation Feedback
Table
3-5). The structure starts at address 0x7FF0 (address 0xFFF0 in XDATA)
Table 3-5. Flash Lock-Protection Bit Structure Definition
Name
DBGLOCK
FREE SPACE
PAGELOCK[FLASH_PAGES-2:0] Page-lock bits. There is one bit for each of the up to 128 pages.
Copyright © 2009–2014, Texas Instruments Incorporated
Table
3-5), all debug commands except
Section
3.3.2).
Debug-lock bit
0: Disable debug commands
1: Enable debug commands
On devices with less than 256 KB memory: Code space available for
storing code or constants.
Page-lock bits for unavailable pages are not used.
0: Page locked
1: Page not locked
Flash Programming
Description
Debug Interface
57
